Media
Compartment
Print Unit
Long Side Door
Intermec EasyCoder F2 – Installation & Operation Ed. 1
The media compartment is either covered by a long side door that
completely encloses the print unit and media compartment, or a
short side door that only covers the print unit and gives easy access
to the paper supply (see chapter 9 "Options"). Being held by a mag-
netic lock, both doors can be opened 180 so as to provide full
access to the media compartment in connection with paper load
and cleaning.
The paper supply can be from a rotating spool, a hanger, or from an
external supply behind the printer, also see next page.
Chapter 3 Installation
Paper Supply
Spool
o r
Hanger
Optional rewind unit
with guide shaft
19
