Media Compartment
Description
Themediacompartmentisasstandardcoveredbyalongsidedoorthat
completelyenclosestheprintmechanismandmediacompartment.
(Optionally,theprintercanbefittedwithatwopart"Megatop"that
allowsalargermediarolltobeused.)Thedoorisheldbyamagnetic
lock.Itcanbeopened180°toprovidefullaccesstothemediacompart-
ment.
Themediasupplycanbefromasupplypost,orfromanexternalsupply
offanfoldsbehindtheprinter.Thereisalsoanoptionalrotatingmedia
supplyhub.AlsoseeChapter9,"Options."
Thermal transfer
mechanism
Front door
Print
mechanism
Long side door
Intermec EasyCoder PF4i Compact Industrial—User's Guide (Fingerprint)
Chapter 2—Installation
Optional integral
liner takeup with
guide shaft
