3-20 Chapter 3: Configuring the 2085-IT8-SC/IT-16-SC Using CCW
Channel Status
Name
15,7 DNR<n>
AI_00: Module Status and CJ Sensor Status
Bit Name
8,0 CJS<x>
9,1 UR<x>
10,2 OR<x>
11,3 OC<x>
12,4 DNR<x>
5,6,7 Unused
13 CAL
14 SN
15 MF
Length Name
CJS<x>
1 word
Data
User's Manual Pub. 0300322-01 Rev. B
Description
Data Not Ready
When set to 1, the module is initializing sampled data

3.5.10 Module Status and CJ Sensor Status Bit Definition

Description
CJ Sensor Fault
This bit is set when the CJ Sensor has Open Circuit, Data Not Ready or
Under/Over range fault.
Under Range
When set to 1, indicates the measured value is less than, or equal to, the
defined Under Range value of the CJ Sensor range.
Over Range
When set to 1, indicates the measured value is greater than, or equal to, the
defined Over Range value of the CJ Sensor range.
Open Circuit
When set to 1, indicates the CJ Sensor connection on the terminal block is
open.
Data Not Ready
When set to 1, the module is initializing sampled data.
Bits masked as Unused are set to 0.
Invalid Cal Data
The stored calibration data or checksum is corrupt or invalid.
The module must be factory calibrated before it will operate normally.
Invalid Serial Number Data
The stored serial number checksum is corrupt or invalid.
The module must be factory calibrated before it will operate normally.
Module Fault
Set as global fault if any channel fault or CJ Sensor fault.

3.5.11 CJ Sensor Data for 2085-IT8-SC/2085-IT16-SC

Description
CJ Sensor Data <x>
The Data Type for the CJ Sensor Data is a signed 16-bit integer. The valid
display range in integer format is from -2000 to +9000.
See additional indication conditions in the CJ Sensor feature.
