1-4 Chapter 1, Module Overview
Input Specifications
Thermocouple accuracy
Specifications only apply to 4
Hz and 17 Hz filters
Type J (-210°C to 1200°C)
Type N -100°C to 1300°C)
Type N (-210°C to -100°C)
Type T -170°C to 400°C)
Type T (-270°C to -170°C)
Type K (-170°C to 1370°C)
Type K (-270°C to -170°C)
Type E (-190°C to 1000°C)
Type E (-270°C to -190°C)
Type S (0°C to 1768.1°C)
Type R (0°C to 1768.1°C)
Type B (300°C to 1820°C)
Type C (0°C to 2315°C)
CJC Sensor Range
CJC Profile accuracy
CJC Sensor accuracy
CJC Measurement accuracy
CJC Total accuracy (Sum of
three items above)
Voltage accuracy
Specifications only apply to 4
Hz and 17 Hz filters
±50 mV
±100 mV
Repeatability (at 25 ºC)
Thermocouples
1
These filters do not reject 50/60 Hz. Repeatability for these filters is strongly dependent on how much 50/60Hz noise is in the
system.
User's Manual Pub. 0300322-01 Rev. B
Error at 25 °C, Typical,
Max
±0.4 °C, ±0.6 °C
±0.4 °C, ±0.7°C
±0.8 °C, ±1.5°C
±0.6 °C, ±1.0 °C
±3.0 °C, ±8.0 °C
±1.1 °C, ±1.5 °C
±6.0 °C, ±15.0°C
±0.4 °C, ±0.6 °C
±3.0 °C, ± 6.0°C
±1.0 °C, ± 2.0 °C
±1.0 °C, ±2.0 °C
±1.8 °C, ±4.0 °C
±0.8 °C, ±1.8 °C
-20 ºC to 90 ºC
±2.1 ºC maximum (Correlation between reading and target
terminal)
±0.2 ºC maximum (for 0 ºC to 70 ºC input values)
±0.4 ºC maximum (for full -20 ºC to 90 ºC CJC input values)
±0.2 ºC maximum (for 0 ºC to 70 ºC input values)
±0.5 ºC maximum (for -20 ºC to 90 ºC input values)
±2.5 ºC maximum (for 0 ºC to 70 ºC input values)
±3.0 ºC maximum (for full -20 ºC to 90 ºC CJC input values)
Error at 25 ºC, Max
±20 uV
±20 uV
4 Hz filter 17 Hz filter
Value
Error over -20 °C to 65 °C
Typical, Max
±0.5 °C, ±1.6 °C
±0.5 °C, ±1.3 °C
±1.0 °C, ±2.2 °C
±0.7 °C, ±1.5 °C
±.5 °C, ±14.0 °C
±1.2 °C, ± 2.1 °C
±7.0 °C, ±20.0 °C
±0.5 °C, ±1.2 °C
±3.5 °C, ±10.0 °C
±1.2 °C, ±2.6 °C
±1.2 °C, ±2.6 °C
±2.1 °C, ± 4.5 °C
±1.0 °C, ±4.0 °C
Error over -20 ºC to 65 ºC, Max
±50 uV
±100 uV
60 and 470 Hz filters 1
