Section 1.2
Input Specifications
Input Specifications
Operating Temperature
Storage/Non-Operating
Temperature
Operating Humidity
Storage/Non-Operating
Humidity
Vibration/Operating
Operating Shock
Storage/Non-Operating
Shock
Pollution Level
ESD
Radiated Immunity
Input modes
Inputs per module (8
channels)
Inputs per module (16
channels)
Thermocouple types
Voltage input ranges
Input filters
The default configuration for the modules is for all channels enabled with the
Type J TC setting with the 17 Hz filter in Engineering ×1 units.
The module normally requires no further user intervention. However, if the
module experiences a hard fault condition, you may need to cycle power, or pull
the module from the rack.
The 2085-IT8-SC/2085-IT16-SC modules have the following input
specifications.
Table 1-1. Input/Performance/Environmental Requirements
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
5% to 95%, non-condensing
5% to 85%, non-condensing
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
25 G, peak acceleration, 11±1 ms pulse, half sine
25 G peak acceleration, 11±1 ms pulse, half sine; 35 g for
panel mount.
Meets Pollution Degree 2 requirements.
6kV Indirect (Coupling Plate)
6kV Contact Discharge (to points of initial contact)
8kV Air Discharge (to points of initial contact)
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at
900 and at 1890 MHz
10 V/M with 1 kHz sine-wave 80% AM from 80...2000
MHz
3 V/M with 1 kHz sine-wave 80% AM from 2000...6000
MHz
Thermocouples and millivolt ranges.
8 thermocouple/ millivolt inputs, and 2 CJC input channels
16 thermocouples/ millivolt inputs, and 2 CJC input channels
J, K, T, E, R, S, B, N and C
±50 mV and ±100 mV
4 Hz, 17 Hz, 60 Hz, 470 Hz
Chapter 1: Module Overview
Value
User's Manual Pub. 0300322-01 Rev. B
1-3
