Environmental Tests
Shock (Operating)
(Performance Criteria A)
Shock (Non-operating)
(Performance Criteria B)
Radiated Emissions
Conducted Emissions
ESD immunity
(Performance Criteria B)
Radiated RF immunity
(Performance Criteria A)
EFT/B immunity
(Performance Criteria B)
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
AC Mains Voltage Dips, Interruptions
and Variations
Safety Tests
UL Safety
Test Limits
25 G, 11 ms half-sine (3 mutually perpendicular axes)
25 G (35 G Panel mount), 11 ms half-sine (3 mutually
perpendicular axes)
(Enclosure) Class A, 30 MHz – 1 GHz
Group 1, Class A (AC Mains), 150 kHz – 30 MHz
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 900
& at 1890 MHz
10 V/M with 1 kHz sine-wave 80% AM from 80...2000 MHz
3 V/M with 1 kHz sine-wave 80% AM from 2000...6000
MHz (10 V/M goal)
Signal Ports:
±2 kV at 5 kHz for 5 minutes, Criteria B
Power Ports:
±2 kV at 5 kHz for 5 minutes, Criteria B
Signal Ports:
±2 kV line-earth {CM} at 2 Ω on shielded ports
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
10 VRMS with 1 kHz sine wave 80% AM from 150 kHz...80
MHz on signal and power ports
30 Arms/m
Follow the 61000-4-11.
Table 1-4. Safety Test Specification Table
Industry Standards
UL 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 2-201: Particular
Requirements for Control Equipment (NRAQ, NRAQ7)
CAN/CSA C22.2 No. 61010-1-12 (Safety Requirements for Electrical
Equipment for Measurement, Control,
and Laboratory Use – Part 1: General Requirements)
