It is recommended that before manually or automatically pasting your configuration settings to the textbox
5
of the CCW Configuration tab, be sure to select the Hex Radix indication on both software packages. The
CCW software is unable to receive negative values under Decimal Radix indication.
Chapter 3: Configuring the 2085-IT8-SC/IT-16-SC Using CCW
The Configuration Text dialog appears with your configuration settings
for all the channels.
You can manually copy the settings and paste it to the textbox of the
CCW Configuration tab
7. To automatically copy the generated settings into the textbox of the
CCW Configuration tab, have the textbox visible on the monitor screen,
and then click Copy to CCW button
The utility copies the configuration settings and shows it inside the
textbox.
5
.
.
5
User's Manual Pub. 0300322-01 Rev. B
3-13
