1-8 Chapter 1, Module Overview
Safety Tests
UL Hazardous
Locations
CE EMC Directive
UKCA
FCC
ROROC
Section 1.3
Data Formats
Section 1.4
Hardware
Features
User's Manual Pub. 0300322-01 Rev. B
Industry Standards
ANSI/ISA–12.12.01 Nonincendive Electrical Equipment for Use in Class I,
Division 2 Hazardous (Classified) Locations (NRAG)
CSA C22.2 No. 213-M1987 - Non-incendive Electrical Equipment for use in
Class I Division 2 Hazardous Locations - March 1987 (NRAG7)
Temp code T4 or better, Pollution degree 2, gas groups a,b,c, & d
EN 61131-2 Programmable Controllers: Third Edition 2007-02, Clause 8,
Zones A&B
EN 61000-6-2: Generic Industrial Immunity
EN 61000-6-4: Generic Industrial Emissions
Electromagnetic Compatibility Regulations 2016
BS EN 61131-2, BS EN 61000-6-4, BS EN 61000-6-2
27 CFR Part 15, Class A
Arrêté ministériel n° 6404-15 du 29 ramadan 1436 (16 juillet 2015)
NM EN 61131-2, NM EN 61000-6-4, NM EN 61000-6-2
There are four data input types:
Engineering units ×1
•
Engineering units ×10
•
• Raw/proportional count
• Percentage Full Scale
Channels are wired as differential inputs. Open-circuit detection alerts users to an
open circuit condition. Inputs are protected from electrostatic discharge up to 6
kV for indirect and contact discharge, 8 kV for air discharge.

1.4.1 LED Indicators

A 2085-IT8/IT16-SC module firmware uses a single, green OK LED to show
power or module operational status.
When startup is completed, and all internal tests have passed, the LED is solid
GREEN. If the LED remains off, there is an error with the module: it may not
have power, or the module failed to pass the self-test.
