INVT Goodrive10 Series Operation Manual page 32

Goodrive10 Series Mini VFD
Function
Name
code
Upper limit
of the
P00.04
running
frequency
Lower limit
of the
P00.05
running
frequency
A
frequency
P00.06
command
selection
B
frequency
P00.07
command
selection
Description
The upper limit of the running frequency is the
upper limit of the output frequency of the VFD
which is lower than or equal to the maximum
frequency.
Setting range:P00.05–P00.03
frequency)
The lower limit of the running frequency is that of
the output frequency of the VFD.
The VFD runs at the lower limit frequency if the
set frequency is lower than the lower limit one.
Note: Max. output frequency ≥ Upper limit
frequency ≥ Lower limit frequency
Setting range:0.00Hz–P00.04 (Upper limit of the
running frequency)
Note: Frequency A and frequency B cannot use
the same frequency
frequency source can be set by P00.09.
0:Keypad data setting (correspond to the
keypad potentiometer)
Modify the value of function code P00.10 (set
the frequency by keypad) to modify the
frequency by the keypad.
1: AI1 setting
potentiometer)
2: AI2 setting (corresponding to terminal AI)
Analog input terminal sets the frequency. There
are 2 standard analog input terminal, of which
AI1 is adjusted through digital potentiometer, AI2
(0–10V/0–20mA) can be switched by the
jumper.
Note: when AI2 selects 0–20mA input, 20mA
corresponds to 10V.
100.0% of the analog input corresponds to
P00.03, -100.0%
corresponds to the reverse P00.03.
6: Multi-step speed running setting
The VFD runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the
current running step, and set P10 to select the
(Max.
setting mode.
(corresponding to
of the analog
-27-
Function parameters
Default
50.00Hz
output
0.00Hz
The
0
keypad
2
input
Modify
◎
◎
○
○
