The parameter data is 0032H, that is, 50, so 5.0 is obtained based on the fieldbus scale
(50/10=5.0). In this case, the master identifies that the "Wake-up-from-sleep delay" is 5.0s.

7.3.6 Error message response

Operation errors may occur in communication-based control. For example, some
parameters can only be read, but a write command is transmitted. In this case, the VFD
returns an error message response. Error message responses are sent from the VFD to the
master. The following table describes the codes and definitions of the error message
responses.
Code Name
Invalid
01H
command
Invalid data
02H
address.
Invalid data
03H
value
Operation
04H
failure
05H Password error
06H Data frame error
Parameter
07H
read-only
The command code received by the upper computer is not
allowed to be executed. The possible causes are as
follows:
•
The function code is applicable only on new devices and
is not implemented on this device.
•
The slave is in the faulty state when processing this
request.
For the VFD, the data address in the request of the upper
computer is not allowed. In particular, the combination of
the register address
to-be-transmitted bytes is invalid.
The received data domain contains a value that is not
allowed. The value indicates the error of the remaining
structure in the combined request.
Note: It does not mean that the data item submitted for
storage in the register includes a value unexpected by the
program.
The parameter is set to an invalid value in the write
operation. For example, a function input terminal cannot be
set repeatedly.
The password entered in the password verification address
is different from that set in P07.00.
The length of the data frame transmitted by the upper
computer is incorrect, or in the RTU format, the value of the
CRC check bit is inconsistent with the CRC value
calculated by the lower computer.
The parameter to be modified in the write operation of the
upper computer is a read-only parameter.
-98-
Communication protocol
Meaning
and the number of the
