INVT Goodrive10 Series Operation Manual page 80

Goodrive10 Series Mini VFD
Function
Name
code
Counting
P17.18
value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
PID
P17.23 reference
value
PID
P17.24 response
value
Power
P17.25 factor of
the motor
Current
P17.26 running
time
Current
step of the
P17.27
multi-step
speed
Output
P17.36
torque
Motor
overload
P17.37
count
value
Display the current counting number of the VFD.
Range: 0–65535
Display analog AI1 input signal.
Range: 0.00–10.00V
Display analog AI2 input signal.
Range: 0.00–10.00V
Display PID reference value.
Range: -100.0–100.0%
Display PID response value.
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display current running time of the VFD.
Range:0–65535min
Display the current step of the multi-step speed.
Range: 0–15
Display the output torque. Positive value is in the
electromotion state, and negative value is in the
power generating state.
Range : -3000.0Nm–3000.0Nm
0–100 (Display the "OL1" fault when the count
value is 100.)
Description
-75-
Function parameters
Default Modify
●
0
●
0.00V
●
0.00V
●
0.0%
●
0.0%
●
●
0m
●
0
●
0.0Nm
●
0
