C2 Filter Model Description - INVT Goodrive10 Series Operation Manual

Goodrive10 Series Mini VFD
VFD model
GD10-0R4G-2-B
GD10-0R7G-2-B
GD10-1R5G-2-B
GD10-2R2G-2-B
GD10-0R7G-4-B
GD10-1R5G-4-B
GD10-2R2G-4-B
Note:

The input EMI meets the C3 requirements after an input filter is configured.

The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
C.6.3 C2 Filter model description
Field
identifier
A
B
C
D
E
F
-
FLT P
A B
FLT: Name of the VFD filter series
Filter type
P: Power input filter
L: Output filter
Voltage class
S2: AC 1PH 220V (-15%)–240V (+10%)
04: AC 3PH 380V (-15%)–440V (+10%)
3-digit code indicating the rated current. For example, 016 indicates
16A.
Filter performance
L: General
H: High-performance
Filter application environment
A: Environment Category I (IEC61800-3), C1 (EN 61800-3)
B: Environment Category I (IEC61800-3), C2 (EN 61800-3)
FLT-P04008L-C-G
FLT-P04008L-C-G
FLT-P04006L-C-G
FLT-P04006L-C-G
FLT-P04006L-C-G
FLT-P04006L-C-G
FLT-P04006L-C-G
04
L
016
C D E
Field description
-115-
