C.3 Cable
C.3.1 Power cable
The sizes of the input power cables and motor cables must meet the local regulation.
Note: If the conductivity of the shielding layer of the motor cables cannot meet the
requirements, separate PE conductors must be used.
C.3.2 Control cable
All analog control cables and cables used for frequency input must be shielded cables.
Relay cables need to be those with metal braided shield layers.
Keypads need to be connected by using network cables. In complicated electromagnetic
environments, shielded network cables are recommended.
Note:

Analog signals and digital signals cannot use the same cables, and their cables must be
arranged separately.

Check the insulation conditions of the input power cable of a VFD according to the local
regulations before connecting it.
VFD model
GD10-0R2G-S2-B
GD10-0R4G-S2-B
GD10-0R7G-S2-B
GD10-1R5G-S2-B
GD10-2R2G-S2-B
GD10-0R2G-2-B
GD10-0R4G-2-B
GD10-0R7G-2-B
GD10-1R5G-2-B
GD10-2R2G-2-B
GD10-0R7G-4-B
GD10-1R5G-4-B
GD10-2R2G-4-B
Recommended
2
cable size(mm )
RST
PE
UVW
1.5 1.5
1.5 1.5
1.5 1.5
2.5 2.5
2.5 2.5
1.5 1.5
1.5 1.5
1.5 1.5
2.5 2.5
2.5 2.5
1.5 1.5
2.5 2.5
2.5 2.5
Size of connectable cable
2
(mm )
PB
RST P1 and
(+) and
UVW (+)
(-)
1.5 1.5 1.5
1.5 1.5 1.5
1.5 1.5 1.5
2.5 2.5 2.5
2.5 2.5 2.5
1.5 1.5 1.5
1.5 1.5 1.5
1.5 1.5 1.5
2.5 2.5 2.5
2.5 2.5 2.5
1.5 1.5 1.5
2.5 2.5 2.5
2.5 2.5 2.5
-110-
Optional peripheral accessories
Terminal
screw
PE
1.5 M3
1.5 M3
1.5 M3
2.5 M3
2.5 M3
1.5 M3
1.5 M3
1.5 M3
2.5 M3
2.5 M3
1.5 M3
2.5 M3
2.5 M3
Tightening
torque
(Nm)
0.56
0.56
0.56
0.8
0.8
0.56
0.56
0.56
0.8
0.8
0.8
0.8
0.8
