Operating Install Wizard

Turning On System

Make sure the antenna has a clear view of the sky. Press the Power button on the front of the Antenna Control
Unit (ACU) then a wait few minutes for system startup. Once the antenna finds the satellite, the "POWER"
status lights will be lit Green.

Accessing AptusNX

The network is automatically configured by DHCP without the need for additional PC IP configuration.
1. Connect an Ethernet cable from the Management LAN port on the front of the ACU to the LAN port of PC.
2. The network connection is established automatically.
3. Use the following IP address to access Intellian AptusNX page.
• IP Address: 192.168.2.1 (Default)
ACU - Front Panel
Management LAN Port
Figure: Front Panel Management LAN Port Connection
PC
(Not supplied)
40
Operating Install Wizard
