  • Page 1 GX100NX 2 1.05 m Maritime Global Xpress Terminal Installation & Operation User Guide...
  • Page 2 © 2022 Intellian Technologies, Inc. All rights reserved. Intellian and the Intellian logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other countries. The GX100NX 2 is a trademark of Intellian Technologies, Inc. Intellian may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document.

  • Page 3: Table Of Contents

    Chapter 1. Precautions 1.1 Warnings, Cautions, and Notes 1.2 General Precautions Chapter 2. Certifications Chapter 3. Introduction 3.1 Intellian GX100NX 2 Introduction 3.2 Intellian GX100NX 2 Features Chapter 4. Planning Installation 4.1 Selection of Installation Site 4.1.1 Minimize Satellite Blockage 4.1.2 Avoid RF Interference...
  • Page 4 GX100NX 2 - Maritime Global Xpress Terminal 6.6.2 Dual Antenna System Configuration (Optional) 6.7 BDT Cable Connection 6.7.1 BDT Back Panel Connectors 6.7.2 BDT Connector Pinout Guide 6.7.3 Connecting Power to BDT 6.7.4 Connecting BDT to Antenna 6.7.5 Connecting BDT to the Switch Router 6.7.6 Connecting BDT to Ship's Gyrocompass...
  • Page 5 Table of Contents 9.6.3 Backup to USB 9.6.4 Restore From USB Chapter 10. Using AptusNX 10.1 Introduction 10.2 Accessing AptusNX for BDT 10.3 Main Page (Page Login) 10.4 Top Menus 10.5 Account Menu 10.5.1 Account 10.5.2 Registration 10.5.3 System 10.5.4 User Manager 10.6 Dashboard 10.6.1 How to Add &...

  • Page 6: List Of Figures

    GX100NX 2 - Maritime Global Xpress Terminal List of Figures Chapter 4. Planning Installation Figure 1: Elevation Limit of Obstacles Figure 2: Potential RF Interference Figure 3: RF Hazard Precautions Figure 4: Radome and Pedestal Figure 5: Front Panel of BDT...
  • Page 7 Table of Contents Chapter 6. Installing Below Deck Unit (BDU) Figure 19: BDT Dimensions Figure 20: 19-inch Rack Mount BDT Figure 21: ACU Dimensions Figure 22: 19-inch Rack Mount ACU Figure 23: Single Antenna System Configuration (Basic Antenna System) Figure 24: Dual Antenna System Configuration Figure 25: BDT Back Panel Connectors Figure 26: Connecting Power to BDT Figure 27: BDT to Antenna Cable Connection...

  • Page 8: Chapter 1. Precautions

    UV rays when assembled according to Intellian instructions, and when the supplied approved hardware and sealants are used. Under no circumstances should an Intellian radome be covered by any protective covering that adheres, bonds, or clings to the surface, whether by self-adhesion or tension.

  • Page 9: Chapter 2. Certifications

    Chapter 2. Certifications FCC Part 15 Subpart B Declaration of Conformity We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon (Chungho-ri), Pyeongtaek-si, Gyeonggi-do 17709 Korea declare under our sole responsibility that the product(s) described in the below to which this declaration relates is in conformity with the requirement of the FCC Part 15 Subpart B.
  • Page 10 §25.218 (i) (4): For cross-polarized transmissions in the plane tangent to the GSO arc and in the plane perpendicular to the GSO arc Intellian Technologies, Inc. declares that GX100NX 2 complies with the threshold level as defined in §25.218(i) (1)(2)(4) Product description...
  • Page 11 Introduction RED Declaration of Conformity We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-862, Korea declare under our sole responsibility that the product(s) described in the below to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the Radio Equipment Directive (2014/53/EU).
  • Page 12 GX100NX 2 - Maritime Global Xpress Terminal UK-CA Declaration of Conformity We, Intellian Technologies, Inc. located at 18-7, Jinwisandan-ro, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 17709, Korea declare under our sole responsibility that the product(s) described in the below to which this declaration relates is in conformity with the essential requirements and other relevant requirements according to UK legislation Electrical Equipment (Safety) Regulations 2016 (S.I.

  • Page 13: Chapter 3. Introduction

    The system with Transceiver can use dual-polarization for both Tx and Rx with several possible topologies. The GX100NX 2 can be easily upgraded with the 9W High Power Transceiver. There is no need to replace the BDT and no additional components are required. Simply and easy upgrade 9W Transceiver to benefit from high throughput service.

  • Page 14: Intellian Gx100Nx 2 Features

    The system with Transceiver can use dual-polarization for both Tx and Rx with several possible topologies. The GX100NX 2 can be easily upgraded with the 9W High Power Transceiver. There is no need to replace the BDT and no additional components are required. Simply and easy upgrade 9W Transceiver to benefit from high throughput service.

  • Page 15: Chapter 4. Planning Installation

    Planning Installation Chapter 4. Planning Installation The antenna installation requires extreme precaution and safety measures given its size and weight. Failure to follow the correct installation process may lead to injury of the installer and/or cause damage to the system. In order to maximize the performance of the system, a thorough review of this installation guide is strongly recom- mended, as well as executing the installation process as it is noted in this manual.

  • Page 16: Avoid Rf Interference

    GX100NX 2 - Maritime Global Xpress Terminal 4.1.2 Avoid RF Interference Do not install the antenna near the high power shortwave radar. Most radar transmitters emit RF energy within an elevation range of -15° to +15°. For this reason, it is recommended to position the antenna at least 15 feet (4.6 m) away from the radar.

  • Page 17: System Package

    Planning Installation 4.2 System Package 4.2.1 Above Deck Unit (ADU) The ADU includes an antenna pedestal inside a radome assembly unit. The pedestal consists of a satellite antenna main dish with RF components mounted on a stabilized pedestal. The radome protects the antenna pedestal assembly unit from the severe marine environment.

  • Page 18: Antenna Control Unit (Acu) (Optional: For Dual Antenna System)

    GX100NX 2 - Maritime Global Xpress Terminal 4.2.3 Antenna Control Unit (ACU) (Optional: for Dual Antenna System) In Dual Antenna System, the secondary antenna needs to be connected to non-Core Module installed Antenna Control Unit (ACU) instead of BDT. The following functions are supported by ACU.

  • Page 19: Packing List

    Planning Installation 4.2.4 Packing List Before beginning installation, make sure you have all the included components. Above Deck Unit (ADU) Package Item Q'ty Size Description Above Deck Unit (ADU) Radome and Pedestal Quick Installation Guide (QIG) Installation guide (A Copy) Radiation safety distance RF Hazard Sticker (30 m) label...
  • Page 20 GX100NX 2 - Maritime Global Xpress Terminal ACU Components Box (Optional: for Dual Antenna System) The ACU Components Box can be purchased separately. Item Q'ty Size Description 431 mm x 350 mm x Antenna Control Unit (ACU) Antenna Control Unit (ACU) 44.3 mm...

  • Page 21: System Cables (Customer Supplied)

    - Optimal tightening torque for N type RF connector: 1.5 N-m - Maximum RF loss at 2 GHz: 16 dB including connectors 4.3.2 Gyrocompass Cable (Customer Furnished) General types of gyrocompass cables are recommended for the compatible connection to Intellian antennas which are used in various environments of vessels. Standard...

  • Page 22: Unpacking System Package

    GX100NX 2 - Maritime Global Xpress Terminal 4.4 Unpacking System Package CAUTION • The package box on the pallet should be lifted by a forklift. • Follow the steps in order for easy and safe unpacking. CAUTION 1. Open the side panel with an attached sticker paper ( Wooden Crate Unpack Guide ) by removing the fixing screw (1 ea) and clips (6 ea).
  • Page 23 Planning Installation 3. Running Diagnostic Tests: This step is optional. After removing one of the side panels, you can run the diagnostic tests to verify the condition of the antenna. First, prepare an RF Cable (customer supplied) to connect the antenna and the BDT. 3-1.
  • Page 24 GX100NX 2 - Maritime Global Xpress Terminal 5. Remove the fixing screws (7 ea) that secures the three side panels, then detach all the panels remaining the antenna on the pallet. : 7 ea...

  • Page 25: Chapter 5. Installing Above Deck Unit (Adu)

    Installing Above Deck Unit (ADU) Chapter 5. Installing Above Deck Unit (ADU) 5.1 Antenna Dimensions Confirm the height and diameter of the antenna unit shown in the following figure before installing it. The mounting surface and overall space occupied by the antenna must be sufficient for the fully constructed radome on top of its base frame.

  • Page 26: Antenna Mounting Hole Pattern

    GX100NX 2 - Maritime Global Xpress Terminal 5.2 Antenna Mounting Hole Pattern Use the supplied mounting template when drilling mounting holes on the mast. The hole placement for the antenna must match the mounting hole pattern on the template. WARNING When reusing an existing mast, check the condition of holes on the mast and make sure those are proper to use compared to the hole locations and sizes printed on the mounting template.

  • Page 27: Designing Mast (Example Only)

    Installing Above Deck Unit (ADU) 5.3 Designing Mast (Example Only) The installation mast must be robust enough to prevent flex, vibration, and sway when an external force is exerted on the mast with antenna and radome. Refer to the following mast drawings for more details. NOTE This is a general example of designing a mast.

  • Page 28: Figure 11: Recommended Size Of Mast (Option 1)

    GX100NX 2 - Maritime Global Xpress Terminal Option 1. When Installing Cable on Outside of Mast This method is generally recommended. Unit: mm (inch) 247.5 (9.74) Antenna Mounting Hole Ø15.0 (0.59), 4ea Ø445.0 (17.52) Plate Thickness Ø200.0 (7.87) Min. 10.0 (0.39) Max.

  • Page 29: Chapter 5. Installing Above Deck Unit (Adu)

    Installing Above Deck Unit (ADU) Option 2. When Installing Cable Through Inside Mast Unit: mm (inch) 247.5 (9.74) Antenna Mounting Hole Ø15.0 (0.59), 4ea Gooseneck Ø110.0 (4.33) Ø180.0 (7.08) Ø200.0 (7.87) Ø445.0 (17.52) Plate Thickness Ø200.0 (7.87) Min. 10.0 (0.39) Max.

  • Page 30: Routing Rf Cable On Mast (Example Only)

    GX100NX 2 - Maritime Global Xpress Terminal 5.4 Routing RF Cable on Mast (Example Only) The cable must be routed from the antenna and through various areas of the ship to end up at the antenna control unit. When pulling the cables in place, avoid sharp bends, kinking, and excessive force. After placement, seal the deck penetration gland and tie the cable securely in place.

  • Page 31: Figure 14: Routing Cable Through Inside Of Mast

    Installing Above Deck Unit (ADU) Option 2. Routing Cable Through Inside Mast 1. Before placing the radome on the mast, route the cable through the gooseneck on the deck and the built-in gooseneck on the mast for easier placing of the RF Cable through the inside of the mast as shown in the picture.

  • Page 32: Removing Antenna From Wooden Pallet

    GX100NX 2 - Maritime Global Xpress Terminal 5.5 Removing Antenna from Wooden Pallet Four radome brackets secure the antenna to the pallet. To remove the radome bracket, follow the procedures. 1. Remove the hex head wrench bolts (2 ea) on each radome bracket using a wrench.

  • Page 33: Placing Antenna Above Mast

    • DO NOT reuse the removed bolt and washers. CAUTION 5.6 Placing Antenna Above Mast The Intellian antenna comes with the lifting straps pre-mounted from the factory. Check the condition of the lifting strap and ensure the shackle is tightened up. Lift the antenna above the mast using a crane and carefully lower down the antenna toward the mast.

  • Page 34: Inserting Waterproof Foam

    GX100NX 2 - Maritime Global Xpress Terminal 5.7 Inserting Waterproof Foam The supplied waterproof foam must be inserted to prevent water penetration into the radome before mounting the radome on the mast. Make sure the waterproof foam is positioned where the following picture shows.

  • Page 35: Mounting Antenna On Mast

    Installing Above Deck Unit (ADU) 5.8 Mounting Antenna on Mast 1. Bring M12 x 80L Hex Bolt sets (4 ea) for antenna-mast assembly from the BDT box. 2. Place the antenna on the mast and align the mounting holes of the antenna with those of the mast. 3.

  • Page 36: Connecting Rf Cable To Antenna

    GX100NX 2 - Maritime Global Xpress Terminal 5.9 Connecting RF Cable to Antenna Connect the RF Cable (customer supplied) from the ANTENNA port of the BDT to the RF connector inside the cable entry of radome. Both side of the connection cable should be terminated using suitable tools. After the connection, securely fix the cable in place using cable ties.
  • Page 37 Installing Above Deck Unit (ADU) 2. Terminate N(M) connector on the end of the RF Cable. Intellian recommends using a genuine cable connector and tools. Refer to the cable termination instructions provided by the manufacturer to terminate the N connector.

  • Page 38: Switching On Power Box

    GX100NX 2 - Maritime Global Xpress Terminal 5.10 Switching On Power Box Access the ADU modules inside the radome to check that the power switch is on through the radome hatch. Make sure that there is sufficient free space underneath the ADU to open the radome hatch.

  • Page 39: Chapter 6. Installing Below Deck Unit (Bdu)

    Installing Below Deck Unit (BDU) Chapter 6. Installing Below Deck Unit (BDU) 6.1 Selection of BDU Installation Site The BDU should be installed below the deck in a location that is dry, cool and ventilated. The front panel of BDU should be easily accessible to users. 6.2 BDT Dimensions Confirm the dimension of the BDT before installing it.

  • Page 40: Mounting Bdt

    GX100NX 2 - Maritime Global Xpress Terminal 6.3 Mounting BDT Mounting BDT on 19-inch Rack The BDT can installed to 19" rack using the two rack mount brackets which can be found from the BDT box. Attach the rack mount brackets to the sides of the BDT using flat head screws. Connect cables to the back side of the BDT.

  • Page 41: Acu Dimensions (Optional: For Dual Antenna System)

    Installing Below Deck Unit (BDU) 6.4 ACU Dimensions (Optional: For Dual Antenna System) Confirm the dimension of the ACU before installing it. Unit: mm (inch) 431 (16.96) 466 (18.34) 485 (19.09) Figure 21: ACU Dimensions...

  • Page 42: Mounting Acu (Optional: For Dual Antenna System)

    GX100NX 2 - Maritime Global Xpress Terminal 6.5 Mounting ACU (Optional: For Dual Antenna System) Mounting ACU on 19-inch Rack The ACU can installed to 19" rack using the two rack mount brackets which can be found from the ACU box.

  • Page 43: Antenna System Configurations

    Installing Below Deck Unit (BDU) 6.6 Antenna System Configurations For the proper operation of the satellite communication system, the required components must be connected as shown in the figure. Separate purchase of a switch router and ship’s gyrocompass may be needed.

  • Page 44: Dual Antenna System Configuration (Optional)

    GX100NX 2 - Maritime Global Xpress Terminal 6.6.2 Dual Antenna System Configuration (Optional) The dual system configuration consists of two VSAT antennas, one BDT, one ACU. The BDT has embedded Dual Antenna Mediator function, which is capable of controlling and managing two VSAT antenna systems simultaneously.

  • Page 45: Bdt Cable Connection

    Installing Below Deck Unit (BDU) 6.7 BDT Cable Connection 6.7.1 BDT Back Panel Connectors The following figure shows the BDT back panel. Below Deck Terminal (BDT) Power Antenna LAN 2 LAN 4 Secondary NMEA 2000 Console Wi-Fi Rx/Tx Dongle NMEA 0183 (GYRO) LAN 1 LAN 3...
  • Page 46 GX100NX 2 - Maritime Global Xpress Terminal Secondary Rx and Tx Connectors RF F Type Female Conductor Function Inner DATA Outer Antenna Connector RF N Type Female Conductor Function Inner RX, TX, FSK, REFERENCE, POWER Outer NMEA 2000 Input Mini-C 5-Pin Male...
  • Page 47 Installing Below Deck Unit (BDU) Console (iARM Interface) - RS232 Connector D-Sub 9-Pin Male Signal DBG Rx (iARM) DBG Tx (iARM) LAN Connectors (LAN 1~LAN 4) 1 2 3 4 5 6 7 8 RJ-45 Female Signal Wi-Fi Dongle Connector USB A Female Signal +5 V...

  • Page 48: Connecting Power To Bdt

    GX100NX 2 - Maritime Global Xpress Terminal 6.7.3 Connecting Power to BDT Connect the power cord from the power supply to the power connector (100~240 VAC) of BDT. Power (100~240 VAC, 50/60 Hz, 3 A) 100~240 VAC (Power Supply) Figure 26: Connecting Power to BDT 6.7.4 Connecting BDT to Antenna...

  • Page 49: Connecting Bdt To The Switch Router

    Installing Below Deck Unit (BDU) 6.7.5 Connecting BDT to the Switch Router Connect an Ethernet Cable from the LAN 2 (RJ45) port of the BDT to a LAN (RJ45) port of the Switch Router. LAN 2 Switch Router (Not supplied) Figure 28: BDT to Switch Router Cable Connection...

  • Page 50: Connecting Bdt To Ship's Gyrocompass

    For satellite tracking, connect a gyrocompass used on ship to the antenna system through the gyrocompass interface of the BDT. Intellian BDT supports NMEA 0183 and NMEA 2000 gyrocompass inputs. If the gyrocompass has a different output standard, a compass converter should be used to supply The NMEA 2000 gyrocompass needs to be purchased separately.

  • Page 51: Connecting Bdt To Additional Secondary Acu (Optional)

    Installing Below Deck Unit (BDU) 6.7.7 Connecting BDT to Additional Secondary ACU (Optional) For the Dual Antenna System, the antenna system needs to be installed with a BDT (primary) and a ACU (secondary). 1. Connect a RF cable (F to F) from the Secondary Rx (F) port of the Primary BDT to the Primary Rx (F) port of Secondary ACU.

  • Page 52: Bdt To Pc Communication Setup

    1. Connect an Ethernet cable from the Management LAN port on the front of the BDT to the LAN port of 2. The network connection is established automatically. 3. Use the following IP address to access Intellian AptusNX page. • IP Address: 192.168.2.1 (Default)

  • Page 53: Usb Connection

    Installing Below Deck Unit (BDU) 6.8.2 USB Connection • Using Right Side USB Port on BDT Front Panel Connect a USB memory stick to the right side USB port on the front panel of BDT for the log download, backup/restore antenna settings, and firmware upgrade. •...

  • Page 54: Wi-Fi Connection

    6.8.3 Wi-Fi Connection Connection through Wi-Fi Dongle Intellian provides the Wi-Fi Dongle for Wi-Fi connection. You can connect PC to the BDT via Wi-Fi for easy management and control whenever you are on the vessel. 1. Connect an Ethernet cable from the Management LAN port on the front panel of BDT to a LAN port of The network connection is established automatically.

  • Page 55: Chapter 7. Operating Install Wizard

    1. Connect an Ethernet cable from the Management LAN port on the front of the BDT to the LAN port of 2. The network connection is established automatically. 3. Use the following IP address to access Intellian AptusNX page. • IP Address: 192.168.2.1 (Default) 4.

  • Page 56: Starting Install Wizard

    GX100NX 2 - Maritime Global Xpress Terminal 7.3 Starting Install Wizard The Install Wizard will give you a guide by going through the steps of setup for the antenna system commissioning. We highly recommend using this wizard to complete the installation and commissioning of the system.
  • Page 57 Operating Install Wizard ü Step 2: GPS Set the GPS position of the vessel for the satellite searching. Check the GPS status connected to the antenna system. The colored indicator next to the title shows the GPS status. Make sure the GPS indicator is Blue (blinking).
  • Page 58 GX100NX 2 - Maritime Global Xpress Terminal ü Step 4: Set Bow Offset For setting BOW offset, select one of two satellite tracking types and a trackable satellite. • Step 1: Select a satellite under the Satellite List, then click the Start Searching button.
  • Page 59 Operating Install Wizard ü Step 6: Target Satellite Set the target satellite to track. There are two methods for selecting a target satellite. NOTE The following images in this step show when the Open AMIP modem is used. NOTE (Option 1: Using Satellite Controlled by Modem) This method is generally recommended.
  • Page 60 GX100NX 2 - Maritime Global Xpress Terminal ü Step 7: Report NOTE The following image in this step shows when the Open AMIP modem is used. NOTE The configuration report is displayed. You can save the results to the BDT by...

  • Page 61: Chapter 8. Operating Bdt

    Operating BDT Chapter 8. Operating BDT 8.1 Introduction 8.1.1 Below Deck Terminal (BDT) The BDT has the embedded Dual Antenna Mediator function, which is capable of controlling and managing two VSAT antenna systems simultaneously in the dual antenna system. The Below Deck Terminal (BDT) controls the various settings of the antenna. Antenna System Type Target Antenna Single Antenna System...

  • Page 62: Bdt Display Menu

    GX100NX 2 - Maritime Global Xpress Terminal 8.1.3 BDT Display Menu The following figure shows the BDT display menu. GPS: M U A P HDG:120.4 TRACKING 128.0 E The following table shows the function of each touch key. Item Description Satellite Lock Displays the satellite lock status.
  • Page 63 Operating BDT Item Description Below Deck Terminal (BDT) includes built in Satellite Modem. Displays the modem status. Item LED Display Description The modem is powered on. The modem is in normal operating conditions. The modem has a serious fault or failure in Warning software, hardware, or configuration.

  • Page 64: Startup

    GX100NX 2 - Maritime Global Xpress Terminal 8.2 Startup With the system is installed and power is applied, the BDT display will show the following sequence. ü Startup Intellian XXXXXXX Intellian's model name is displayed. ANTENNA INFO ü Initialize Antenna Information ü...
  • Page 65 Operating BDT When the antenna is controlled by AptusNX, the BDT displays the control mode status. ü Control Mode Status REBOOT (Reboot Mode, Setup Mode, Test Mode, One Touch ANTENNA Commissioning) SETUP MODE TEST MODE ONE TOUCH COMMISSIONING If the antenna does not communicate with BDT, the COMMUNICATION ERROR is displayed. COMMUNICATION ERROR...

  • Page 66: Diagnosis

    GX100NX 2 - Maritime Global Xpress Terminal 8.3 Diagnosis Executes antenna Diagnosis test and shows the real-time diagnosis result. Press Move Key GPS: HDG:120.4 TRACKING 128.0 E ü Main Display DIAGNOSIS ü Diagnosis Display Press DIAG ALL Select Key DIAG : CODE 101 ü...
  • Page 67 Operating BDT Item Description Displays the diagnosis code. Code Test The data communication between the antenna and the BDT is tested. The azimuth axis is tested. The elevation axis is tested. The cross-level axis is tested. Not Available Not Available The rate sensor is tested.

  • Page 68: Antenna Information

    GX100NX 2 - Maritime Global Xpress Terminal 8.4 Antenna Information Displays the Antenna/BDT serial number, PCU/STAB/BDT/iARM Version of the product. Press Move Key GPS: HDG:120.4 TRACKING 128.0 E ü Main Display Press Move Key DIAGNOSIS ü Diagnosis Display DIAG ALL ü...

  • Page 69: Interface Information

    Operating BDT 8.5 Interface Information Displays the modem/heading type in use and the network connection status. Press Move Key GPS: HDG:120.4 TRACKING 128.0 E ü Main Display Press Move Key DIAGNOSIS ü Diagnosis Display DIAG ALL Press ü Antenna Information Display XXXXXXX Move Key Product model name and antenna/BDT serial...

  • Page 70: Usb Function

    GX100NX 2 - Maritime Global Xpress Terminal 8.6 USB Function To use this function, a USB Memory Stick must be connected to the USB port (the right side USB port on the fron of the BDT). The USB Function supports the four menus (LOG DOWNLOAD, FIRMWARE UPLOAD, BACKUP TO USB, RESTORE FROM USB).

  • Page 71: Log Download

    Operating BDT 8.6.1 Log Download Downloads all data logs to the USB memory. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD BACKUP TO USB RESTORE FROM USB USB FUNCTION BACK Press LOG DOWNLOAD FIRMWARE UPLOAD Select Key BACKUP TO USB...

  • Page 72: Firmware Upload

    GX100NX 2 - Maritime Global Xpress Terminal 8.6.2 Firmware Upload To use Firmware Upload function, you must follow the folder structure guide to configure the folders properly. It supports up to FAT32. The antenna system is upgraded with the FWP file in the designated folder of a USB memory.

  • Page 73: Backup To Usb

    Operating BDT 8.6.3 Backup to USB Backs up the antenna setting files to the USB. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD x3 times BACKUP TO USB RESTORE FROM USB USB FUNCTION BACK Press LOG DOWNLOAD...

  • Page 74: Restore From Usb

    GX100NX 2 - Maritime Global Xpress Terminal 8.6.4 Restore From USB Restores the antenna setting by using the setting files saved in USB. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD x4 times...

  • Page 75: Chapter 9. Operating Acu (Optional)

    Operating ACU (Optional) Chapter 9. Operating ACU (Optional) 9.1 Introduction 9.1.1 Antenna Control Unit (ACU) To use the Dual Antenna System (optional), the antenna system needs an additional Secondary ACU and antenna to support the Dual Antenna System operation. The Antenna Control Unit (ACU) controls the various settings of the antenna. Antenna System Type Target Antenna Dual Antenna System (optional)

  • Page 76: Acu Display Menu

    GX100NX 2 - Maritime Global Xpress Terminal 9.1.3 ACU Display Menu The following figure shows the ACU display menu. F:20.119/18.250 RX:L TX:R TRACKING 128.0 E HDG:120.4 GPS: M U A S The following table shows the function of each touch key.

  • Page 77: Startup

    9.2 Startup With the system is installed and power is applied, the ACU display will show the following sequence. ü Startup Intellian XXXXXXX Intellian's model name is displayed. ANTENNA INFO ü Initialize Antenna Information ü Initialize Elevation Angle EL INITIALIZE ü...
  • Page 78 GX100NX 2 - Maritime Global Xpress Terminal When the antenna is controlled by AptusNX, the ACU displays the control mode status. REBOOT ü Control Mode Status Reboot Mode, Setup Mode, Test Mode ANTENNA SETUP MODE TEST MODE If the antenna does not communicate with ACU, the COMMUNICATION ERROR is displayed.

  • Page 79: Diagnosis

    Operating ACU (Optional) 9.3 Diagnosis Executes antenna Diagnosis test and shows the real-time diagnosis result. Press Move Key F:20.119/18.250 RX:L TX:R TRACKING 128.0 E ü Main Display HDG:120.4 GPS: DIAGNOSIS ü Diagnosis Display Press DIAG ALL Select Key DIAG : CODE 101 ü...
  • Page 80 GX100NX 2 - Maritime Global Xpress Terminal Item Description Displays the diagnosis code. Code Test The data communication between the antenna and the ACU is tested. The azimuth axis is tested. The elevation axis is tested. The cross-level axis is tested.

  • Page 81: Antenna Information

    Operating ACU (Optional) 9.4 Antenna Information Displays the Antenna/ACU serial number, PCU/STAB/ACU/iARM Version of the product. Press Move Key F:20.119/18.250 RX:L TX:R TRACKING 128.0 E ü Main Display HDG:120.4 GPS: Press Move Key DIAGNOSIS ü Diagnosis Display DIAG ALL ü Antenna Information Display PRODUCT : XXXXXXX Product model name and antenna/ACU serial...

  • Page 82: Interface Information

    GX100NX 2 - Maritime Global Xpress Terminal 9.5 Interface Information Displays the modem/heading type in use and the network connection status. Press Move Key F:20.119/18.250 RX:L TX:R TRACKING 128.0 E ü Main Display HDG:120.4 GPS: Press Move Key DIAGNOSIS ü Diagnosis Display...

  • Page 83: Usb Function

    Operating ACU (Optional) 9.6 USB Function To use this function, a USB Memory Stick must be connected to the USB port (the right USB port on the front of the ACU). The USB Function supports the four menus (LOG DOWNLOAD, FIRMWARE UPLOAD, BACKUP TO USB, RESTORE FROM USB).

  • Page 84: Log Download

    GX100NX 2 - Maritime Global Xpress Terminal 9.6.1 Log Download Downloads all data logs to the USB memory. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD BACKUP TO USB RESTORE FROM USB USB FUNCTION...

  • Page 85: Firmware Upload

    Operating ACU (Optional) 9.6.2 Firmware Upload To use Firmware Upload function, you must follow the folder structure guide to configure the folders properly. It supports up to FAT32. The antenna system is upgraded with the FWP file in the designated folder of a USB memory.

  • Page 86: Backup To Usb

    GX100NX 2 - Maritime Global Xpress Terminal 9.6.3 Backup to USB Backs up the antenna setting files to the USB. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD x3 times BACKUP TO USB...

  • Page 87: Restore From Usb

    Operating ACU (Optional) 9.6.4 Restore From USB Restores the antenna setting by using the setting files saved in USB. Press USB FUNCTION Move Key BACK ü USB Function Menu Display LOG DOWNLOAD FIRMWARE UPLOAD x4 times BACKUP TO USB RESTORE FROM USB USB FUNCTION BACK LOG DOWNLOAD...

  • Page 88: Chapter 10. Using Aptusnx

    Chapter 10. Using AptusNX 10.1 Introduction With the embedded AptusNX software, the antenna can be monitored, controlled, and diagnosed remotely from anywhere, anytime through TCP/IP protocol. It saves your time and cost generated by various mainte- nance activities such as operating firmware upgrades, tracking parameter resets, and system diagnosis, etc.. 10.2 Accessing AptusNX for BDT 1.

  • Page 89: Main Page (Page Login)

    Using AptusNX 10.3 Main Page (Page Login) The Intellian software Aptus provides different user access levels to protect the system for safe operation. Depending on the user level, the accessible range of function in the software can be limited. Log into the BDT by typing in User ID and Password. The followings are the factory default values.

  • Page 90: Top Menus

    GX100NX 2 - Maritime Global Xpress Terminal 10.4 Top Menus Once you log in, the following information and menus are displayed. Item Description Target Satellite Displays the name of the targeted satellite. When clicking this top menu area (marked in the red dotted box), the "Quick Status Screen"...

  • Page 91: Account Menu

    Using AptusNX 10.5 Account Menu 1. Click the button to manage the user account 2. The Account, System, and User Mgr. menus are for the user management. Click the Logout button to log- out of the AptusNX web page. 10.5.1 Account Item Description Account...

  • Page 92: Registration

    GX100NX 2 - Maritime Global Xpress Terminal 10.5.2 Registration xx-xxxx-xxxx xxxxxxxxxxx Item Description Enters product registration information for the convenient use of a product. Click Registration the Register (Update) button to apply the settings to the system. Displays the antenna information.

  • Page 93: System

    Using AptusNX 10.5.3 System xx cm / xx inch xx-xx-xxxx xx-xxxxx xxxxxxxxxxx xxxxxxxxxxx v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 192.168.2.1 192.168.2.1 xx:xx:xx xxxx-xx-xx xx:xx:xx Item Description Displays system information such as the antenna, S/W version, and network IP System address.

  • Page 94: User Manager

    GX100NX 2 - Maritime Global Xpress Terminal 10.5.4 User Manager Editable User Permissions Menu Item Description The captain with admin permissions can control and manage user permissions User Manager separately. To create a new user, click the Add User button. Then the pop-up window is Add User opened.

  • Page 95: Dashboard

    Using AptusNX 10.6 Dashboard The Dashboard is displayed to provide quick monitoring of the antenna status. The Dashboard helps you ar- range panels on a single screen while providing you with a broad view of a variety of information at once. The dashboard contains multiple panels, which can easily customize the structure of your dashboard and arrange your panels in various ways to make them more readable and user-friendly.

  • Page 96: How To Arrange Dashboard Layout

    GX100NX 2 - Maritime Global Xpress Terminal Removing Panels 1. On the right side of the page, you will see the gear icon to edit your dashboard. To start editing, click on the gear icon indicated by the red mark.

  • Page 97: How To Use Shortcut Settings

    Using AptusNX 10.6.3 How to Use Shortcut Settings Each panel on the dashboard provides a shortcut function. Using the Shortcut button on right side of the panel, you can easily access the detailed information and manage the each panel's settings. 1.

  • Page 98: System Tools

    GX100NX 2 - Maritime Global Xpress Terminal 10.8 System Tools This menu sets and displays the F/W Upgrade, iARM Upgrade, iARM Save&Reboot, Satellite Library, Spectrum Graph and Graph function. 10.8.1 Firmware Upgrade v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00...
  • Page 99 Using AptusNX Antenna Firmware Upgrade (Manual Upgrade method) Procedures: 1. Choose Manual Upgrade from the pull-down menu of Upgrade Method. Browse and select the upgrade package file to upload. Click on the Upload button to transfer the Firmware package file ("*.fwp") to iARM module.
  • Page 100 GX100NX 2 - Maritime Global Xpress Terminal 4. During the upgrade process, the window will display process status. v0.91.001 v0.91.002 v0.91.004 v0.91.005 v1.26 v1.27 v1.05 v1.06 v1.05 v1.06 5. If the firmware is successfully upgraded, it will display as the Success. Click the Confirm button to close the pop-up window.

  • Page 101: Iarm Upgrade

    Using AptusNX 10.8.2 iARM Upgrade v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 v1.00 Item Description iARM Upgrade Upgrades the firmware of iARM module. Browse and select the iARM firmware file to upload and click Start Upload button.

  • Page 102: Iarm Save & Reboot

    GX100NX 2 - Maritime Global Xpress Terminal iARM Upgrade Procedures: 1. Browse and select the iARM firmware file (.tgz) that you wish to upgrade. Click on "Start Update" button to update the iARM firmware. Wait until the page is loaded.

  • Page 103: Satellite Library

    Using AptusNX 10.8.4 Satellite Library Item Description Satellite Library Sets the satellite library information. Reads or manages satellite information from the library. • Get Library from BDT (ACU): Obtains satellite library file from the BDT (ACU). Satellite List • Get Library from PC: Obtains the satellite library file from the PC. •...

  • Page 104: Graph

    GX100NX 2 - Maritime Global Xpress Terminal 10.8.5 Graph Multi Chart View Single Chart View AZ & EL View Item Description This view provides information on the Signal Level, EL Graph, AZ Absolute, AZ Graph Relative, Heading in the Multi Chart, Single Chart or AZ & EL formats.

  • Page 105: System Troubleshooting

    Using AptusNX 10.9 System Troubleshooting This menu sets and displays the Diagnosis, Antenna Log, Antenna Event Log and Support function. 10.9.1 Diagnosis Item Description Diagnosis Executes antenna diagnosis test to check the antenna status. Select the checkbox (full diagnosis test or single diagnosis test) before modifying the settings.
  • Page 106 GX100NX 2 - Maritime Global Xpress Terminal 2. Once the diagnosis starts, the page will indicate test status. It should take a few minutes to complete the test. 3. After the diagnosis is completed the system shows the diagnosis results of each item. You can save the results to the BDT by clicking the Save Result button and print this page by clicking the Print button.

  • Page 107: Antenna Log

    Using AptusNX 10.9.2 Antenna Log Item Description Antenna Log Displays the antenna log data. Turns on/off the GPS log download option. Click the Apply button to apply the GPS Log Option settings to the system. Any log data within three months can be downloaded. Select the duration on the calendar view that you want to show.

  • Page 108: Antenna Event Log

    • View Manual: click the View Manual button to open the manual web page. Manual and Help • Support Desk: click the Support Desk button to open Intellian's contact details for support. Provides answers to frequently asked questions about the product.

  • Page 109: System Setting

    Using AptusNX 10.10 System Setting This menu sets and displays the Ship, Antenna, Satellite, Network, Modem Info, SNMP, Backup & Restore and Mediator function. 10.10.1 Ship Setting Item Description Ship Sets the ship information and block zone.
  • Page 110 • Current Bow Offset (º): Enter the Bow Offset Range (0 – 360°). Click the Apply button to apply the settings to the system. It is important to set up the blockage zones for Intellian VSAT. The VSAT system can be programmed with relative azimuth and elevation sectors to create up to five zones for transmission mute.

  • Page 111: Antenna Setting

    Using AptusNX 10.10.2 Antenna Setting NOTE The "Set Rate Sensor Bias" NOTE function must be used by experienced engineers only. NOTE Item Description Sets current antenna position and search parameters. Antenna Setting These parameters should only be changed by an authorized service technician. Improper setting of these parameters will render your system inoperable.
  • Page 112 Refer to the replacement manual for detailed procedures. The separate device (e.g. level indicator) for manual adjustment is not provided by Intellian. Enter Setup Mode to modify settings.
  • Page 113 Using AptusNX Item Description NOTE: The rate values of the azimuth, elevation, and cross-level axes were calibrated to the optimal condition at the factory prior to shipment. If the additional rate adjustment is required, make sure that the antenna is placed on a rigid and flat platform.

  • Page 114: Tracking Satellite Setting

    GX100NX 2 - Maritime Global Xpress Terminal 10.10.3 Tracking Satellite Setting Item Description Tracking Satellite Sets the current tracking satellite settings. Setting Sets the current tracking satellite settings. • Satellite Name: Enter the satellite name. • Longitude (º): Enter the satellite orbit position.

  • Page 115: Network Configuration

    Using AptusNX 10.10.4 Network Configuration This function is available after performing the "10.8.3 iARM Save & Reboot" on page 102. NOTE When clicking the "Apply" button after editing the system settings, this pop-up message will appear. If you want to automatically save NOTE and reboot the system, select the checkbox and click the "Confirm"...
  • Page 116 • UDP Port: Sets the management port. Configuration • Message Type: Selects message type (Intellian message level) to send to the management server (Lower number indicates higher emergency). • Syslog Target Level: If you select this target level, the management server receives a log message equal to or less than this level.

  • Page 117: Modem Info

    Using AptusNX 10.10.5 Modem Info...
  • Page 118 GX100NX 2 - Maritime Global Xpress Terminal Item Description Below Deck Terminal (BDT) includes built in Satellite Modem. Modem Info Displays the modem's operating status and information. Each indicator is displayed modem's operating status as colors. Item LED Display Description...

  • Page 119: Backup & Restore Setting

    Using AptusNX 10.10.6 Backup & Restore Setting Item Description Backup & Backs up & Restores the antenna setting files and the iARM files. Restore Setting • Antenna Backup: Back up antenna settings and parameters to PC by clicking on the Backup button. Antenna Backup •...

  • Page 120: Mediator Setting (Optional: For Dual Antenna System)

    Secondary Antenna's AptusNX View Item Description Intellian's new BDT has embedded Dual Antenna Mediator function, which can be utilized to switch between two Intellian VSAT antenna systems simultaneously. Mediator Setting When one antenna is blocked by obstacles or has suddenly lost service, another antenna will immediately provide fail-safe operation to maintain the highest levels of system performance and reliability.
  • Page 121 Using AptusNX Item Description This menu is differently shown in the Primary Antenna's AptusNX and the Secondary Antenna's AptusNX. To clearly distinguish the primary antenna and the secondary antenna, enter a description to each antenna. • Primary: Enter the description for the primary antenna in AptusNX (Editable). Antenna This menu is not shown for the secondary antenna in AptusNX.

  • Page 122: Chapter 11. Specification

    GX100NX 2 - Maritime Global Xpress Terminal Chapter 11. Specification 11.1 Technical Specification Antenna System Antenna Radome Height 1458 mm (57.4") Antenna Radome Diameter Ø1379 mm (54.3") Antenna Reflector Diameter Ø1050 mm (41.3") Antenna Unit Weight (with Radome) 110 kg (242.5 lbs)

  • Page 123: Environmental Specification

    RJ 45 (4 ea), TCP/IP connection Input power 100 ~ 240 V AC, 50/60 Hz, 3.3 A 11.2 Environmental Specification Test Intellian Standard Operational IEC-60945 (-25 °C to +55 °C, Power On) Temperature IEC-60945 (-40 °C to +80 °C, Powered On and a non-...

  • Page 124: Chapter 12. Warranty

    (3) YEAR of parts and TWO (2) YEAR of factory repair labor to return the system to its original operational specification. Warranty periods commence from the date of shipment from Intellian facility, or date of installation which is come sooner. Providing maximum 6 months Warranty additionally if submission of authorized form which is described installation occurs within 6 months from the shipment date.

  • Page 125: Chapter 13. Appendix

    Appendix Chapter 13. Appendix 13.1 Appendix A. Tightening Torque Specification This table shows the recommended values of tightening torques. Bolt Size Tightening Torque (N-m) M2.5...

  • Page 126: Appendix B. Starting Dual Antenna System (Optional)

    GX100NX 2 - Maritime Global Xpress Terminal 13.2 Appendix B. Starting Dual Antenna System (Optional) Intellian's new BDT has embedded Dual Antenna Mediator function, which can be utilized to switch between two Intellian VSAT antenna systems simultaneously. When one antenna is blocked by obstacles or has suddenly lost service, another antenna will immediately provide fail-safe operation to maintain the highest levels of system performance and reliability.

  • Page 127: Appendix C. Performing One Touch Commissioning

    Appendix 13.3 Appendix C. Performing One Touch Commissioning Perform the One Touch Commissioning after the first-time connection of the GX terminal and BDT, cable replacement or band conversion. Take the following steps for the One Touch Commissioning. 1. Connect an Ethernet cable from the Management LAN port on the BDT front panel to the LAN port of BDT - Front Panel Management LAN Port (Customer supplied)

This manual is also suitable for:

Gx100nx 2 hpV5-11g-v3x3nV5-11g-00x3nV5-11g-d3sx3nV5-11g-v3x4nV5-11g-00x4n ... Show all

Table of Contents
