  • Page 1 Installation and Operation User Guide Marine Satellite Communication Antenna System...
  • Page 3 © 2010 Intellian Technologies Inc. All rights reserved. Intellian and the Intellian logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other countries. The v-Series and the v60 is trademarks of Intellian Technologies, Inc. Intellian may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document.
  • Page 4 INDEX...

  • Page 5: Table Of Contents

    INDEX CERTIFICATIONS INTRODUCTION Introduction to Intellian v60 Features of Intellian v60 System Configurations INSTALLING THE ANTENNA System Package Planning the Installation Antenna Installation INSTALLING THE ACU Mounting the ACU Ship Gyro Connection OPERATING THE ACU Introduction Normal Mode Setup Mode...

  • Page 6: Certifications

    CERTIFICATIONS R&TTE Declaration of Conformity (DoC) We, Intellian Technologies, Inc. located at 2F Dongik Bldg., 98 Nonhyun-dong, Kangnam-gu, Seoul 135-080, Korea declare under our sole responsibility that the product(s) described in the below to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the Radio and Telecommunications Terminal Equipment(R&TTE) Directive (1999/5/EC).
  • Page 7 Intellian v130, 125cm Ku-band maritime VSAT antenna system -14.0 dBW/ 4KHz Intellian Technologies, Inc. declares that the above antennas will maintain a pointing error of less than or equal to 0.2 degree under specified ship motion conditions in accordance with the requirements of §25.222 (a)(1)(ii).
  • Page 8 – Marine Satellite Communication System INTRODUCTION Introduction to Intellian v60 Features of Intellian v60 System Configurations...

  • Page 9: Introduction Introduction To Intellian V60

    SCPC, MCPC, TDMA or Spread Spectrum transmissions. Designed for ocean vessels in the recreational, commercial or oil and gas market segments, as well as military vessels, the v60 offers "always on" high-quality broadband communications, in even the roughest weather and sea conditions.

  • Page 10: Features Of Intellian V60

    Best solution for all kinds of vessels The v60 is the best solution for all kinds of vessels that require the satellite broadband connection around the globe. The major RF components are designed and manufactured by Intellian’s solid in-house engineering to achieve superior antenna gain and xpol isolation recognized among the best performances in the industry.

  • Page 11: System Configurations

    For your satellite communication system to work properly, the system will have to be connected with all of the provided components properly, as shown in the figure below. Separate purchase of a satellite modem, ship’s gyrocompass, Intellian Dual VSAT Mediator are required.

  • Page 12: System Package

    – Marine Satellite Communication System INSTALLING THE ANTENNA System Package Antenna Unit ACU (Antenna Control Unit) Installation Kit Planning the Installation Selection of Antenna Installation Site Configure Radiation Hazard/Blockage Zones System Cables Power Requirement Tools Required for Installation Installation...

  • Page 13: Installing The Antenna System Package

    INSTALLING THE ANTENNA System Package The package of Intellian v60 consists of antenna unit, ACU and installation kit box. Antenna unit Installation kit box...
  • Page 14 – Marine Satellite Communication System Antenna Unit The antenna unit includes an antenna pedestal inside a radome assembly unit. The pedestal consists of a satellite antenna main dish with RF components mounted on a stabilized pedestal. The radome protects the antenna pedestal assembly unit from the severe marine environment.
  • Page 15 INSTALLING THE ANTENNA ACU (Antenna Control Unit) ACU provides power to the antenna and BUC (Block Up Converter). The digital VFD (Vacuum Fluorescent Display) allows for easy operation of the ACU, even in the dark. Antenna Control Unit Front panel Rear panel The functions of the ACU are as follows, •...
  • Page 16 – Marine Satellite Communication System Installation Kit Contains the items required for securing the antenna unit and ACU to the vessel. Antenna Q’ty Description Size Remark Hex. Bolt M8 x 50L Flat Washer Antenna-Deck Spring Washer Hex Head Wrench...
  • Page 17 INSTALLING THE ANTENNA Other Components Item Image Q’ty Description Size Remark Rack ACU - 19 inch Rack Bracket Table ACU-Table ACU(Modem Rx) RG6 Cable to Modem Antenna(Modem Tx) to RG6 Cable 15 m Modem & Antenna(ACU Rx) to ACU(Antenna Rx) Antenna(BUC In) to BUC Power Cable 15 m...

  • Page 18: Planning The Installation

    Obstacle Configure Radiation Hazard/Blockage Zones It is important to setup the radiation hazard or blockage zones for Intellian VSAT communication systems. The ACU can be programmed with relative azimuth and elevation sectors to create up to five zones where transmit power would endanger personnel who are frequently in that area or blockage exists.
  • Page 19 1.25 mm Up to 50 meters 2.30 mm Up to 70 meters 3.00 mm Up to 120 meters 5.00 mm Power Requirement Intellian v60 has been designed to work on a vessel’s power supply rated at 100- 240 V AC.
  • Page 20 – Marine Satellite Communication System Tools Required for Installation 8 mm Spanner Power Drill 11 mm Spanner Cross-Head Screwdriver 13 mm Spanner Minus-Head Screwdriver 4 mm Allen key 5 mm Allen key...

  • Page 21: Antenna Installation

    INSTALLING THE ANTENNA Antenna Installation Unpacking the wooden crate of v60 Step 1. Remove the top panel and 8 pins from the hinges of the wooden crate.
  • Page 22 – Marine Satellite Communication System Step 2. Remove ACU box and installation kit box.
  • Page 23 INSTALLING THE ANTENNA Step 3. Remove 4 shipping blots that mount the antenna to the pallet.
  • Page 24 – Marine Satellite Communication System Step 4. Open the top radome and remove the shipping restraints ( bracket mounted to the antenna pedestal and tie wrap fixed the azimuth axis). M6 Dome Washer M6 Hex Wrench Bolt...
  • Page 25 INSTALLING THE ANTENNA...
  • Page 26 – Marine Satellite Communication System Antenna Dimensions The method of installation and mounting of antenna may vary with vessel design but the following procedures are applicable in most situations, and will result in a secure and effective installation. Confirm the height and diameter of the antenna before installing it.
  • Page 27 INSTALLING THE ANTENNA Antenna Mounting Templates The mounting holes must be in the exact same place as shown in the diagram below. 1 cm(0.4") Holes BOW direction 30.4 cm (12") 45.8 cm (18") Radome Bottom Ø 45.8 cm (18”)
  • Page 28 – Marine Satellite Communication System Installing the System Cables The cables must be routed from the antenna through the deck and through various ship spaces to the antenna control unit. When pulling the cables in place, avoid sharp bends, kinking, and the use of excessive force.
  • Page 29 INSTALLING THE ANTENNA RF Cable Connections Ensure that the power switch is off during the installation period and all the cables are connected properly between the antenna control unit and the power switch box. Using tie wraps supplied with radome, secure the RF cables connected to the power switch box.
  • Page 30 However, Intellian strongly recommends to restraint the antenna pedestal properly during underway conditions when power is removed from the antenna. The normal operating condition for the v60 is to remain powered up at all times.
  • Page 31 INSTALLING THE ANTENNA Position the Radome The radome should be positioned with the BOW marker aligned as close as possible to the ship’s centerline. Recommended size of the support pedestal Base Panel 0.8 cm (0.3”) Supporting Pole Appr Ø10 cm (3.9”)

  • Page 32: Mounting The Acu

    INSTALLING THE ACU Mounting the ACU 19” Rack Mount Type Table Mount Type ACU Dimensions Selection of ACU Installation Site Connecting the System Connecting the System with a Ship’s Gyro Connecting the System without a Ship’s Gyro ACU Connector Guide...
  • Page 33 INSTALLING THE ACU Mounting the ACU Intellian supplies two type of mounting methods (a) 19” Rack Mount Type and (b) Table Mount Type to mount your ACU. 19" Rack Mount Type 19” Rack Mount Type - The ACU should be installed using the two supplied Rack Mounting Brackets which allow for a side 19”...
  • Page 34 – Marine Satellite Communication System ACU Dimensions 47.4 cm (18.6") Dimension of ACU 45.4 cm (17.8") 43.1 cm (17") 4.4 cm (1.7") POWER TRACKING ERROR Antenna Control Unit Power 46.5 cm (18.3") 48.5 cm (19.1") Selection of ACU Installation Site The ACU should be installed below deck, in a location that is: Dry, cool, and ventilated.

  • Page 35: Ship Gyro Connection

    Connecting the System with a Ship’s Gyro The ship’s gyrocompass provides true heading input to the antenna which easily allows the antenna to target and acquire the desired satellite. Therefore, Intellian always recommend the user to connect a ship’s gyro to the antenna through the gyro interface on the ACU.
  • Page 36 For a vessel where the ship’s gyro compass is not installed or is difficult to be connected, the Intellian Gyro-Free satellite search function will be automatically enabled to allow the antenna to lock onto the desired satellite without requiring an external heading input.
  • Page 37 INSTALLING THE ACU ACU Connector Guide • Synchro Connector ACU Synchro Port D-Sub 9 pin Male connector D-Sub 9 pin Female Supplied Component Signal Signal SYNCHRO_R2 SYNCHRO_R1 SYNCHRO_R3 SYNCHRO_S2 SYNCHRO_S1 • Console Port ACU Console Port D-Sub 9 pin Male connector D-Sub 9 pin Female Supplied Component Signal...

  • Page 38: Operating The Acu

    OPERATING THE ACU OPERATING THE ACU Introduction Normal Mode Setup Mode Installation Settings Antenna Settings Manual Search Setup Antenna LNB pol Angle Search Parameters Setup Antenna Parameters Setup Block Zone Antenna Diagnostic Test Satellite Settings Load Satellite Edit Satellite Information Add Satellite Information Check NID System Settings...

  • Page 39: Introduction

    OPERATING THE ACU Introduction This section of the handbook describes how to setup your system after installing the ACU. It includes the following functions: Mode Arrow Keys ACU Soft Keys PC Cable Status Return Function Number Power (USB) Keys Switch Soft Key Functions Soft key Function...

  • Page 40: Normal Mode

    – Marine Satellite Communication System Normal Mode Startup With the system installed and power applied, the ACU screen will show the following sequence. Start up I N T E L L I A N T E C H N O L O G I E S I N C .
  • Page 41 OPERATING THE ACU Monitoring Antenna Current Status When the ACU power is on, it displays the status of the antenna. The current status of the antenna is displayed as shown below. Current search status S E A R C H 1 1 3 8 .
  • Page 42 – Marine Satellite Communication System Tracking & Heading N B D F : 1 2 4 7 0 0 0 B W : 1 0 0 0 S I G : 3 0 1 information 0 0 4 . 5 3 E 5 2 .

  • Page 43: Setup Mode

    OPERATING THE ACU Setup Mode Enter the SETUP mode simply follow the instructions below. Searching / Tracking mode T R A C K I N G 1 3 8 . 0 E T E L S T _ 1 8 S I G : 3 0 1 A Z : 2 9 2 .

  • Page 44: Installation Settings

    A search pattern 1 or 3 will be initiated according to which Gyro Type is selected and the existence of the gyro input. Ensure that the supported Gyro Type is set correctly. For v60, if the ship’s gyrocompass output is Step-by-Step (SBS), separate purchase of a gyro converter is required.
  • Page 45 OPERATING THE ACU Gyro search mode Setting of Heading Device GYRO TYPE* Existence of Heading NMEA/ Ground NO DEVICE Data Device Synchro Test NMEA SYNCHRO w/ Heading Data Search 1 Search 3 Search 3 GROUND TEST w/out Heading Data Search 1 Search 1 Search 3 Modem port &...

  • Page 46: Antenna Settings

    – Marine Satellite Communication System Antenna Settings Manual Search Search the desired satellite manually. Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
  • Page 47 OPERATING THE ACU Setup Antenna LNB pol Angle Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. Antenna menu + A N T E N N A + S A T E L L I T E...
  • Page 48 – Marine Satellite Communication System Search Parameters Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
  • Page 49 OPERATING THE ACU Search 1 (Gyro Free) Search Pattern 3° 2° 1° Target Satellite EL Position 0° -1° -2° -3° Revolution (AZ direction) Search 1 antenna motion Target EL Angle Target EL Angle + 0.5° Target EL Angle - 0.5° Turn 1 Turn 2 Turn 3...
  • Page 50 – Marine Satellite Communication System Setup Antenna Parameters These parameters should only be changed by an authorized service technician. Improper setting of these parameters will cause your system to perform improperly. Setup mode S E T U P M O D E ? Y E S 1.
  • Page 51 OPERATING THE ACU Set detect & tracking NBD D E T E C T N B D T R A C K I N G N B D 0 4 0 0 2 0 6. Set DETECT NBD and TRACKING NBD when NBD (Narrow band detection) mode of TRACKING SIGNAL is chosen to be used (Range: 1-200).
  • Page 52 – Marine Satellite Communication System Idle mode & I D L E M O D E R E B O O T A N T E N N A Reboot antenna O F F 8. Set IDLE MODE and REBOOT ANTENNA The antenna is balanced at factory.
  • Page 53 OPERATING THE ACU Setup Block Zone Up to 5 block or radiation hazard zones can be programmed with relative azimuth and elevation sectors. Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. Antenna menu + A N T E N N A + S A T E L L I T E...
  • Page 54 – Marine Satellite Communication System Block zone 2 Z O N E 2 B L O C K O F F 5. ZONE 2 to ZONE 5 BLOCK setting is same as ZONE 1 BLOCK. Press OK key to set ZONE 2 BLOCK and set next parameter.
  • Page 55 OPERATING THE ACU Antenna Diagnostic Test Refer to the diagnosis codes for the test results. Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. Antenna menu + A N T E N N A + S A T E L L I T E...
  • Page 56 – Marine Satellite Communication System Diagnosis Code: CODE 101: The data communication between the antenna and the ACU is tested. CODE 102: The azimuth motor is tested. CODE 103: The elevation motor is tested. CODE 104: The cross-level motor is tested.

  • Page 57: Satellite Settings

    OPERATING THE ACU Satellite Settings Load Satellite Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. Satellite menu + A N T E N N A + S A T E L L I T E...
  • Page 58 – Marine Satellite Communication System Edit Satellite Information Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
  • Page 59 OPERATING THE ACU DVB verifiy method D V B V E R I F Y S K E W O F F S E T D V B D E C O D E + 0 . 0 6. Edit satellite DVB VERIFY* method and SKEW OFFSET. DVB VERIFY will be only activated and applied when DVB mode of TRACKING SIGNAL is chosen to be used.
  • Page 60 – Marine Satellite Communication System Set DVB tracking D V B F R E Q . S Y M B O L N I D frequency 1 1 7 4 7 M H Z 2 1 3 0 0 K H Z 0 X 0 0 A D 9.
  • Page 61 OPERATING THE ACU Add Satellite Information Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. Satellite menu + A N T E N N A + S A T E L L I T E + S Y S T E M...
  • Page 62 – Marine Satellite Communication System Set LNB local frequency S E L E C T L O C A L T R A C K I N G S I G N A L 1 0 0 0 0 M H Z N B D 6.
  • Page 63 OPERATING THE ACU Save S A V E ? Y E S 10. Press LEFT arrow key to move cursor to YES and press OK key to save and execute the current settings. Or press RIGHT arrow key to move cursor to NO and press OK key to abort and return to the main display.

  • Page 64: System Settings

    – Marine Satellite Communication System System Settings Set LNB Local Oscillator Frequency Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
  • Page 65 OPERATING THE ACU Set Location Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. System menu + A N T E N N A + S A T E L L I T E + S Y S T E M...
  • Page 66 6. Entry of ships heading is not required when your system is connected to a NMEA0813 or 1:1 Synchro Heading output. Ensure that the supported Gyro Type is set correctly. For v60 if the ship’s gyrocompass output is Step-by-Step (SBS), separate purchase of a gyro converter is required.
  • Page 67 E T H E R N E T 4. USE MEDIATOR is to enable the usage of MEDIATOR if the antenna is connected to the Intellian dual VSAT Mediator. NOTE: USE MEDIATOR must be disabled if there is no MEDIATOR connected to the ACU. Improper setting of this parameter will cause your ACU’s modem interface working incorrectly.
  • Page 68 – Marine Satellite Communication System Set modem protocol P R O T O C O L G P S O U T S E N T E N C E I / O C O N S O L E G P G L L 5.
  • Page 69 OPERATING THE ACU EXT lock & TX mute E X T . L O C K A C T I V E T X M U T E A C T I V E activation L O W L O W 7.
  • Page 70 – Marine Satellite Communication System Default process type D E F A U L T P R O C E S S T Y P E L O A D D E F A U L T 4. Press UP and DOWN arrow keys to select DEFAULT PROCESS TYPE* Press OK key to set the parameter and the processing message will be displayed.
  • Page 71 OPERATING THE ACU Display Versions Setup mode S E T U P M O D E ? Y E S 1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode. System menu + A N T E N N A + S A T E L L I T E + S Y S T E M...
  • Page 72 – Marine Satellite Communication System PC CONTROLLER SOFTWARE Introduction PC to ACU Communication Setup Main Menu Controller Menus Position & Manual Search Tracking Information of Current Satellite Tracking Information of Library Version, Tracking Parameter & Block Zone Diagnosis, Search Parameter & Sensor Adjust...

  • Page 73: Pc Controller Software Introduction

    PC CONTROLLER SOFTWARE Introduction The PC Controller Software of Intellian v60 has been created for the user to easily set up the antenna by using the user’s personal computer. Antenna PC controller...

  • Page 74: Pc To Acu Communication Setup

    Refer to page 104 for changing the ACU’s IP address. WARNING: The data volume will grow very quickly if Network Communication is in use. Intellian recommends to use Remote Web Access to access the ACU (refer to page 86).
  • Page 75 PC CONTROLLER SOFTWARE • Enable the Usage of External Lock & TX Mute - Connect a RJ45 cable from the Ethernet connector on the ACU to the modem or connect a 9 pin serial cable from the RS232/422 connector on the ACU to the modem.

  • Page 76: Main Menu

    – Marine Satellite Communication System Main Menu Main menu • Controller Menus - Position (GPS, Heading, Bow) & Manual search - Tracking Information of Current Satellite - Tracking Information of Library - Version, Tracking Parameter & Block Zone - Diagnosis, Search Parameter & Sensor Adjust - Communication Information •...
  • Page 77 PC CONTROLLER SOFTWARE In “SETUP” mode, “Back Up Position” or “Restore Position” message will pop up if “Backup” or “Restore” button is pressed. Backup File (*.ibf) and Report File (*.rpt) will be generated on the PC if “Back Up to PC” button is pressed. You can open a report file using notepad software.

  • Page 78: Controller Menus

    – Marine Satellite Communication System Controller Menus Position & Manual Search Set the GPS and ship’s heading information to acquire the satellite signal and use move step function to find the satellite signal manually. Antenna angle, GPS and ship’s heading information Antenna Current GPS - Antenna Current GPS: Display current antenna GPS and Ship’s heading information.
  • Page 79 PC CONTROLLER SOFTWARE Tracking Information of Current Satellite Set the tracking mode and tracking frequency of the current satellite. Set the LNB local frequency to its corresponding voltage power supply. Set the current satellite tracking information Satellite Information - Satellite information: Display the current satellite name, longitude position and satellite skew.
  • Page 80 - Load satellite: Upload the pre-programmed satellite information in the library. Library - Open library from PC: Open the satellite library file from the supplied Intellian CD or from the external hard drive/PC. (File format: *.ilf) - Upload library to ACU: Upload the satellite library file to ACU.
  • Page 81 - Display current block zones by azimuth and elevation sectors. Up to 5 blockage zones can be programmed. NOTE: DVB and NBD parameter settings should only be changed by an authorized service technician. Improper setting of these parameters will render your system inoperable. Consult Intellian for changing antenna parameters.
  • Page 82 – Marine Satellite Communication System Diagnosis, Search Parameter & Sensor Adjust Set the tilt sensors and calibrate rate sensors. Set the antenna search parameters. Run an antenna diagnostic test. Display antenna versions and parameters Tilt Sensor Bias - Tilt sensor bias: Adjust the two solid-state tilt sensors used to provide absolute cross-level tilt of the antenna and elevation feedback to eliminate long-term pointing drift (error).
  • Page 83 PC CONTROLLER SOFTWARE Rate Sensor - Rate sensor: Rate sensor is to calibrate DC voltage output from the three rate sensors used to sense antenna motion in azimuth, elevation and cross-level axes. The DC voltage output from each of the rate sensors may be vary by an amount which is directly proportional to the direction and rate of motion induced on it..

  • Page 84: Remote Web Access

    – Marine Satellite Communication System REmOTE WEb ACCESS Introduction Main Page Antenna Settings General Information Current Status Ship Information Antenna Position Tracking Information Parameter Setting Modem Setting Block Zone Setting Diagnosis Satellite Information Antenna / ACU Firmware Upgrade Firmware Upgrade...
  • Page 85 REMOTE WEB ACCESS Introduction With embedded remote access function, the v-Series can be monitored, controlled, and diagnosed remotely from anywhere, anytime through the TCP/IP protocol. This not only can save tremendous time but also save the cost generated from the hundreds of routine maintenance activities such as operating firmware upgrades, tracking parameters resets, and system diagnostic.

  • Page 86: Main

    – Marine Satellite Communication System Main Page • Page Login 1. Enter the ACU's IP address into your web browser's address bar to login into the ACU’s internal HTML page. If this system has not been changed from the ACU’s factory default:...
  • Page 87 REMOTE WEB ACCESS Item Description Control IP Display current IP that controls the ACU. Current IP Display current IP address. Display screen refresh rate and time out. The screen will not refresh once the time-out shows 0:00. Exception: If the Refresh Disable Time is set to “OFF” in the Refresh Rate Network Setting page, then the clock will show “--:--“...
  • Page 88 – Marine Satellite Communication System Antenna Settings General Information Item Description General Display current antenna information. Information Display current antenna information. - Antenna Size: antenna dish size. - Voltage: operation voltage of antenna and ACU. - Antenna Product: antenna model number.
  • Page 89 REMOTE WEB ACCESS Current Status Item Description Current Status Display current antenna status. Display current antenna status. - Search 1: a search pattern 1 will automatically be initiated when the ship’s heading input does not exist / is failed. The search cycle will repeat until the antenna receives the lock signal from the modem or the DVB transponder of the target satellite is decoded by the antenna.
  • Page 90 – Marine Satellite Communication System Ship Information Item Description Ship Information Display GPS and ship’s gyro information. Display current GPS information. - Longitude (East / West) - Latitude (North / South) BOW Offset Display and set bow offset if needed.
  • Page 91 REMOTE WEB ACCESS Antenna Position Item Description Antenna Position Display current antenna position. Display current antenna position. - Relative Azimuth: display antenna relative AZ angle. - Absolute Azimuth: display antenna absolute AZ angle. Current Antenna Position - Elevation: display antenna elevation angle. - LNB Pol Angle: display LNB pol angle.
  • Page 92 – Marine Satellite Communication System Tracking Information Item Description Display or set current tracking mode and tracking frequency of Tracking Information the target satellite. Local Frequency Display LNB’s local frequencies. Display current LNB local Setting (MHz) frequency which is in use and voltage.
  • Page 93 REMOTE WEB ACCESS Parameter Setting WARNING: Ensure the Edit Enable check box is enabled before modifying the settings.
  • Page 94 – Marine Satellite Communication System Item Description Set antenna search & tracking parameters. These parameters should only be changed by an authorized Parameter Setting service technician. Improper setting of these parameters will render your system inoperable. DVB Detect and Tracking Level Threshold: display / set current detect level threshold and tracking level threshold when DVB tracking mode is chosen to be used.
  • Page 95 - Use Mediator: enable the usage of Mediator if the antenna is connected to the Intellian dual VSAT Mediator. Use Mediator must be set to “NO” if there is no MEDIATOR connected to the ACU. Improper setting of this parameter will cause your ACU’s modem interface working incorrectly.
  • Page 96 – Marine Satellite Communication System Block Zone Setting Item Description Block Zone Setting Up to 5 block zones are allowed to be programmed. This is the clockwise of the two points. AZ. START is where the relative azimuth starts and AZ. END is where the relative azimuth Block Zone ends (Range: 0 - 360°).
  • Page 97 REMOTE WEB ACCESS Diagnosis Item Description Diagnosis Execute antenna diagnostic test. Select to run a full diagnostic test or single diagnostic test. - Serial Comm.: test the data communication between the antenna and the ACU. - Motor AZ: test the azimuth motor. - Motor EL: test the elevation motor.
  • Page 98 – Marine Satellite Communication System Satellite Information...
  • Page 99 REMOTE WEB ACCESS Item Description Satellite Information Display the satellite library information. Get Satellite Info from ACU Obtain satellite information installed in the ACU. Select satellite that you wish to track and press Load Load Satellite button to load the selected satellite. - Satellite: display satellite name.

  • Page 100: Antenna / Acu Firmware Upgrade

    – Marine Satellite Communication System Antenna/ ACU Firmware Upgrade Firmware Upgrade Item Description Upgrade antenna and ACU firmware version. Firmware Upgrade Browse and select the firmware package file to upload. Upgrade Steps 1. Select the upgrade package file. 2. Click on “Start Upload” button to transfer the Firmware package file (“*.fwp”) to E2S (Ethernet to serial) module.
  • Page 101 REMOTE WEB ACCESS Firmware upgrade status page 5. It’ll display information about the upgrade process status on full screen. Upgrade process status page 6. If the firmware is successfully upgraded, it’ll display “The firmware update is completed.” 7. Click on "Back to main page" to go out of the screen. To verify the upgraded firmware version, go to the right-side menu of "General information"...
  • Page 102 – Marine Satellite Communication System Roll Back Item Description Roll back antenna and ACU firmware to previous package version Roll Back or latest package version.
  • Page 103 REMOTE WEB ACCESS Upgrade Log Item Description Upgrade Log Display log information of firmware upgrade.

  • Page 104: Ethernet To Serial Settings

    – Marine Satellite Communication System Ethernet-to-Serial Settings Network Setting Item Description Network Setting Modify ACU’s Internal IP address. Modify ACU’s Internal IP address and press Submit button. Go to “Save & Reboot” page and press Save & Reboot button to validate the changes.
  • Page 105 REMOTE WEB ACCESS Serial Setting [1] Item Description Serial Setting Configure Serial port [1] and Serial port [2] Serial Port [1] is to communicate with an external modem via Ethernet. Follow the below instruction to configure Serial port [1] and press Submit button. Go to “Save & Reboot” page and press Save &...
  • Page 106 – Marine Satellite Communication System Serial Setting [2] Serial setting [2] page Item Description Serial Setting Configure Serial port [1] and port [2] Port [2] is to communicate with the PC Control via Ethernet. Follow the below instruction to configure Serial port [2] and press Submit button.
  • Page 107 REMOTE WEB ACCESS SNMP Setting SNMP setting page Item Description Enable or disable the SNMP (Simple Network SNMP v1/v2/v3 Agent Management Protocol) agent. Configure the SNMP v1/v2 attributes (Read-Only, Read- V1/2 Attribution Write, Disable). The community name of SNMP v1 / v2 is “public”.
  • Page 108 – Marine Satellite Communication System Change Password Change password page Item Description Change Password Change your login ID (user name) and password. Enter your current login ID (user name) and new login Change ID ID. Press Submit button to validate the changes that are...
  • Page 109 REMOTE WEB ACCESS Upgrade Steps 1. Click on “Browse” button to select the E2S firmware file (.bin) that you wish to upgrade. 2. Click on “Start Update” button to update the E2S firmware. Wait until the page is loaded. 3. It’ll inform you that the firmware is being uploaded. Firmware uploaded message...
  • Page 110 – Marine Satellite Communication System Save & Reboot Save & reboot page Item Description Save settings to the ACU and reboot or reboot the Save & Reboot system without saving. Save & Reboot Save the modified settings and reboot the system.
  • Page 111 REMOTE WEB ACCESS Access Log Access log page Item Description Access Log Display user’s log information (Date/Time, Login ID and IP)

  • Page 112: Warranty

    1 year’s parts from installation or 18 months from shipment. You are requested to present a copy of the purchase receipt issued by Intellian Technologies, Inc. that presents the date of purchase for after sales service under warranty.

  • Page 113: Technical Specification

    Technical Specification Technical Specification General Approvals CE – conforms to EU Directive 89/336/EEC FCC – verified to CFR47: Part 15 Dimensions Satellite antenna unit 78.0 cm x 84.5 cm (30.7” x 33.3”) Antenna dish diameter 60cm (23.6”) Antenna control unit 43.1cm x 38.1cm x 4.4cm (17”...
  • Page 114 – Marine Satellite Communication System Intellian Technologies, Inc. EMEA & APAC Region Headquarters / R&D Center / Factory 348-5 Chungho-Ri Jinwi-Myeon Pyengtaek-Si, Gyunggi-Do 451-562 Korea Tel: +82 31 379 1000 Fax: +82 31 377 6185 Seoul Office 2F Dongik Bldg., 98, Nonhyun-dong,...
