Antenna System
Antenna Radome Height
Antenna Radome Diameter
Size Antenna Reflector Diameter
A/C Frame Height
A/C Frame Diameter
Antenna
Weight Radome
A/C Frame
Platform
Positioning
Azimuth
Pedestal Motion
Elevation
Range
Cross-level
Pointing Stabilization Accuracy
Roll
Pitch
Ship Motions
Yaw
Turning rate
Frequency
RX Gain
G/T over Rx Range
Frequency
Tx
Gain
Above Deck IFL Termination
Polarization
BUC
LNB
Antenna Control Unit (ACU)
ACU Size
ACU Weight
Display
Key
LED Indicator
USB Port
Ship's Gyrocompass Interface
GPS Interface
1970 mm (77.56")
Ø1900 mm (74.80")
Ø1500 mm (59.06")
652 mm (25.67")
Ø1900 mm (74.80")
< 300 kg (661.4 lbs)
< 80 kg (176.4 lbs)
< 230 kg (507.1 lbs)
Three Axis: Azimuth, Elevation, Cross-level
3-axis Velocity Mode Servo Control: Azimuth, Elevation,
Cross-Level
Unlimited
-15° to +110°
Up to ± 35º
0.2° max in presence of specified ship motions
± 25° at 6 second
± 15° at 6 second
± 8° at 6 second
10°/sec2
10.7 ~ 12.75 GHz Ku-band
43.5 dBi @ 11.7 GHz
> 22.5 dB/K @ 12.75 GHz, 30˚ EL, with radome
13.75 ~ 14.5 GHz Ku-band
45.0 dBi @ 14.25 GHz
1 x 50 Ohm N-type female connector
TX/RX: 10 MHz / 50 MHz / 400 MHz / 433 MHz /
L-band (950 - 2150 MHz)
DC power to BUC & pedestal (and LNB)
Linear polarization
40 W (standard), 16 W / 100 W (optional)
Intellian PLL LNB
431 mm x 350 mm x 44.3 mm
5.2 kg
128 X 64 Graphic OLED (White)
2 button (Direction Key)
3 LEDs for Power, Tracking, Error
2 ea (front panel), 1 ea (rear panel, for Wi-Fi dongle)
NMEA 2000 / NMEA 0183
NMEA Out
