Preparing System Cables

Before installing the system cables, you need to take the following points into consideration.
1. All cables need to be well clamped and protected from physical damage and exposure to heat and humidity.
2. A cable with an acute bend should be avoided.
3. Wherever a cable passes through an exposed bulkhead or deck head, a watertight gland or swan neck
tube should be used.
For cables that run longer than Intellian's recommendations, please consult Intellian Technologies.
• RF Cable (Customer Supplied)
Due to the signal losses across the length of the RF coax on L-Band, Intellian recommends the following 50
ohm coax cable types for standard system installations. For cables that run longer than 120 meters (except
LMR600 coaxial cable type), please consult Intellian Technologies.
* The Maximum DC Resistance of RF Cable is 0.8 Ohm.
* Tightening Torque Value: N Type Connector, 1.5 N-m
Coaxial Cable Type
LMR400
LMR600
• AC Power Cable (Customer Supplied)
Intellian recommends the following size of the AC power cable for standard system installations.
Cable Length Cable
Up to 100 m
Up to 200 m
• Gyrocompass Cable (Customer Furnished)
Due to the environment of various types of vessels, Intellian recommend the general cable types compatible with
the antenna.
Connector Type
Cable Type
Heading Information
Attenuation in dB/100m
(@ 2 GHz)
19.6
12.8
Cross Sectional Area
2.62 mm2
4.17 mm2
NMEA 2000
Mini-C 5 pin connector
5 wires within a single cable
Supports PGN, 127250: Vessel
Heading
Attenuation in dB/m
(@ 2 GHz)
0.196
0.128
AWG (American Wire Gauge) Size
13
11
NMEA 0183
2 pin terminal block connector
2-wires constructed with one
enclosed shield cable
Supports $HEHDT , baud rate 4800,
format 8N1 as standard.
19
Planning Installation
Recommended
Max. Cable Length
80 m
120 m
