ACU Cable Connection

Name of ACU Rear Panel

The following figure shows the ACU's rear panel.
Antenna Control Unit (ACU)
Modem/Primary
Power Cord
Rx/TX Connector

Connecting to Antenna

Connect the "RF Cable (not supplied by Intellian)" from the "ANTENNA" connector on the rear of the ACU to
the "RF Connector" inside cable entry of radome (Antenna).
AC 100~240 V
ACU
Antenna
Connector
Secondary
Rx/TX Connector NMEA 0183 (GYRO)
Figure: Name of ACU Rear Panel
Antenna
TX, RX, 48 VDC Power
Antenna
Figure: ACU to Antenna Cable Connection
Modem RS232/422
Interface
NMEA 2000 & Modem
Console
Input
31
Installing ACU
LAN 2 Port LAN 4 Port
BUC
Wi-Fi
Interface
Dongle
PC
Interface
LAN 1 Port LAN 3 Port
Above Decks
Below Decks
