Hardware FRU procedures

Expansion cards and expansion card risers

VxFlex Ready Node R840 Hardware Field Replacement Unit and Service Manual
96
Table 8 Remove the expansion card riser (continued)
Check Task
List
☐ 9 Remove the faulty expansion card from
the riser, or the expansion card from the
faulty expansion card riser.
☐ 10 Install the replacement expansion card in
the riser or the expansion card in the
replacement expansion card riser.
☐ 11 Install the replacement expansion card
riser or the riser containing the
replacement expansion card.
☐ 12 Install the air shroud.
☐ 13 Install the system cover.
☐ 14 Slide the system into the cabinet.
☐ 15 Connect the I/O cables and power cords. See
☐ 16 Install the bezel.
Perform mandatory software tasks to return the node to operation:
☐ 17 Return the node to operation.
An expansion card is an add-on card that can be installed into an expansion slot on the
system board or a slot on a riser to add enhanced functionality to the system through
the expansion bus.
Note
A System Event Log (SEL) event is logged if an expansion card riser is not supported
or missing. It does not prevent your system from turning on. However, if a F1/F2
pause occurs, an error message is displayed.
This table describes the expansion card riser specifications.
Topic
See Remove the expansion card from the
expansion card riser on page 101.
See Install the expansion card into the
expansion card riser on page 105.
See Install the expansion card risers
page 106.
See the relevant topic, depending on
your system:
Install the non-GPU air shroud
169
Install the GPU air shroud on page 171
See Install the system cover
173.
See Slide the system into the cabinet
page 165.
Connect the I/O cables and power
cords on page 164.
See Install the front bezel
See "Return the node to operation" in
the VxFlex Ready Node Field Replacement
Unit Software Guide .
on
on page
on page
on
on page 166.
