Interrupt (IRQ) Settings

Recommended Interrupt (IRQ)
Settings

GCC IRQ Settings

This section describes the interrupt settings for the GCC and NPU. Table 6-1
lists the recommended IRQ settings for the GCC, and Table 6-2 lists the
recommended IRQ settings for the NPU.
Note: Make sure that COM1 and COM2 are enabled. Use the Ports
icon in the Control Panel Group to make these changes.
Table 6-1 show the recommended GCC IRQ settings.

Table 6-1. GCC IRQ Settings

Recommended IRQs
3
4
5
6
7
2/9
10
11
12
14
15
6-2
firealarmresources.com
Used For
COM2 - serial port
COM1 - serial port
Bus touchscreen
Reserved for floppy drive
LPT1 - parallel port
UL Card I/O
COM3 - UL Card port A serial port
COM4 - UL Card port B serial port
PS2 mouse
Reserved for hard drive
4190 Network Card/Repeater
