Installing the Rack-Mount Components
Installation Procedure
The entire rack setup is assembled and tested at the factory. After testing is
completed, the PC and monitor are removed and packed in their original
shipping cartons. The rails and any other additional items are left on the PC and
monitor. The rack is then shipped as an assembled unit.
Complete the following steps to install the remaining components:
1.
Secure the rack to the floor.
2.
Separate the conduits for the entry of power-limited and non-power limited
supply lines through the bottom plate (there is a label on the bottom plate
showing the desired location for these supply lines).
3.
Install the PC in the rack (the rails are already assembled) and secure it with
10-32 screws (supplied).
4.
Plug the monitor power cord into the PC power outlet.
5.
Plug the PC power cord into the surge protector.
6.
Secure the power wires to the back left rail using the tie wrap provided
(leave a minimum service loop for sliding of the PC).
7.
Secure all other wires (non-power limited) to the back right rail using the tie
wrap provided.
8.
Connect the incoming AC line to the AC termination block.
9.
After you have set up the Rack-Mount GCC, you can continue installing it
on the network.
Caution:
If the GCC is equipped with a Touchscreen, make sure there
1
is a
/
inch space between the bezel and the screen.
16
4-2
firealarmresources.com
Continued on next page
