Getting Started
Unpack the Equipment
Inspect the Equipment
Inventory the Equipment
Related Documentation
When you receive the equipment, immediately inspect the packaging for any
signs of shipping damage. If there are any signs of shipping damage file a claim
with the carrier and notify Simplex.
If there are no signs of shipping damage to the packaging proceed with
unpacking the equipment. Remove all protective plastic covering, Styrofoam
packaging material, and any other packaging material that may have been used.
After the equipment is unpacked, inspect it for damage. Look for cracked cases,
shattered CRTs, etc. If the equipment appears to be damaged notify Simplex; do
not proceed with the equipment installation.
After the equipment is unpacked, locate the shipping papers that came with the
equipment and inventory the equipment received. If equipment is missing, notify
Simplex. If you received all the equipment listed on the shipping papers, proceed
with the hardware installation.
The following is a list of additional documentation that may assist you in the
installation.
•
4120 Graphical Command Center (GCC) Operating Instructions
•
4120 Graphical Command Center (GCC) Programming Instructions
•
4120 Network Processing Unit (NPU) Installation Instructions ..... 574-314
•
Multiport SLI Option Installation Instructions................................ 574-097
•
Field Installation of the 2120 Multiport SLI Option ....................... 574-122
•
4100 Field Wiring Diagram ............................................................ 841-731
•
4100/4120 Interconnect Diagram ................................................... 841-869
1-2
firealarmresources.com
........... 574-312
...... 574-313
