Installing the Software,
Installing the 4190 GCC
Software
(Applies to Both Windows 3.1
and Windows 95 systems
except where noted)
Continued
Notes: 1. Before installing the 4190 GCC software, make sure that
[MS-DOS and Windows 3.1] or Windows 95 is installed.
2. If the GCC is to be used for network programming, install the
4100 Programmer first. This is required to establish proper
ICON setup.
3. The following instructions apply to both Windows 3.1
systems and Windows 95 systems except where noted.
The 4190 Graphical Command Center software comes on high-density, 3.5-inch
diskettes. The 4190 Graphical Command Center diskettes also contain the
following software:
•
The 4190 Programmer software
•
The Network Programmer software
The GCC software is easy to install and requires a little more than 5 Megabytes
of free disk space on the target system. Minimum system requirements are
automatically verified during installation and the installation process is
terminated if the minimum system requirements are not met.
To install the 4190 Graphical Command Center Software, complete the
following steps:
1.
Insert Disk 1 into a floppy disk drive (usually the A: drive) and change to
that drive.
2.
From the Windows 95 Start menu, select Run. The system displays a
command line dialog box.
From the Windows 3.1 Program Manager, select the File|Run menu
options. The system displays a command line dialog box.
3.
On the command line, type A:install and select OK. The system displays
the message: Loading Installation, one moment please... followed by the
Welcome screen.
4. Select Install. If the system detects a previous version of the software, the
dialog shown in Figure 3-1 appears:
Figure 3-1. Previous Version of GCC Software Detected
3-11
firealarmresources.com
Continued on next page
