Quantum™ Hd Drawings - Johnson Controls FRICK QUANTUM HD Maintenance Manual

This table lists the numbers for the drawings that appear on the following pages. The drawings shown here is the latest revi-
sion as of the printing of this manual. These drawings appear here for reference purposes only, and are subject to change
without notice. When installing, or servicing equipment, always refer to the actual drawings that are included with the control
panel for the latest information.
Wiring Diagrams
HD Panel Center Assembly
RXF With Capacity Slide Transmitter
RWFII With Capacity Slide Transmitter
RXF / RXB With Capacity Slide Potentiometer
RWBII With Capacity Slide Potentiometer
RDB
PhD for 32 channel Analog Board
Digital I/O Board 2
Analog I/O Board 2
Other Drawings
DC Power and Communications Harness
AC I/O Harness for Digital Boards 1 and 2
Isolater Repeater Module (Isolates Communications Signals)
Communications Wiring Diagrams
Point-to-Point Field Wiring Diagram
Vyper (up to 565 amps) to Q5 HD Wiring Connections
Vyper (over 565 amps) to Q5 HD Wiring Connections
Enhancer to Q5 HD Wiring Connections
QUANTUM™ HD COMPRESSOR CONTROL PANEL
MAINTENANCE
SECTION 9
QUANTUM™ HD DRAWINGS
Page
64 - 67
68 - 73
74 – 79
80 – 85
86 – 91
92 - 97
98
99 - 100
101 – 102
Page
103
104
105
106
107
Contact Frick Service
Contact Frick Service
Contact Frick Service
090.040-M (MAR 12)
Page 63
Drawing Number
649D5922 Rev. -
649D5943 Rev. -
649D5944 Rev. -
649D5945 Rev. -
649D5946 Rev. -
649D5947 Rev. -
649D5050 Rev. D
649D5948 Rev. -
649D5949 Rev. -
639D0204 Rev. A
639D0203 Rev. -
639C0133 Rev. A
N/A
N/A
649D6002 Rev. -
649D6003 Rev. -
649D6004 Rev. -
