HD COMPRESSOR CONTROL REPLACEMENT PARTS LIST

(Refer to the HD Panel Center Assembly drawing for Item Number references)
Item Legacy New
# Number Number
N/A 640C0057G01 484532
N/A 640C0057G02 484533
N/A 640C0057G11 484534
N/A 640C0057G12 484535
N/A 639A0206H10 484043
24 639A0206H10 484050
23 639A0206H15 484053
N/A 649A1027G14 643440
53 649A1027G11 485874
80 649A1027G21 643460
81 649A1027G31 643461
25 333Q0001418 467096
66 333Q0001191 467024
1 639A0185H10 483963
86 639A0185H30 483966
N/A 639A0185H31 483967
46 639B0120H51 680313
21 639B0114H51 580348
22 639B0114H98 580349
20 * 639B0120H01 680049
20 * 639B0120H11 680311
20 * 639B0120H21 680312
20 * 639B0114H02 580342
20 * 639B0114H12 580345
20 * 639B0114H22 580347
36 639A0243H02 817257
87 * 333Q0001172 467015
87 * 111Q0281061 455056
88 * 333Q0001171 467014
88 * 333Q0000116 466842
88 * 333Q0000789 466949
N/A 333Q0001326 467073
N/A 640C0024G01 484494
N/A 640C0024G02 484495
N/A 649D5210G11 486364
* Based upon system voltage
QUANTUM™ HD COMPRESSOR CONTROL PANEL
MAINTENANCE
SECTION 11
Analog Boards
Analog Board #1 (Replaces existing 32 channel board #1 only - no hardware)
Analog Board #2 (Replaces existing 32 channel board #2 only – no hardware)
Analog Board #1 (Field Upgrade Kit – Includes 32 ch. board #1, connectors & hardware.)
Analog Board #2 (Field Upgrade Kit – Includes 32 ch. board #2, connectors & hardware.)
Circuit Breakers
5 Amp circuit breaker
10 Amp circuit breaker
15 Amp circuit breaker
Connectors
2-Pole connector (P8 – Analog Board)
Connector kit for Input Ch. 1-16 (Analog Board)
Connector kit for Input Ch. 17-24, and Output Ch. 1-8 (Analog Board)
Connector for Power/Communications for Analog Board
Control Power
Filter, Line
Hour meter
2-Pos. Selector Switch (Control Power)
Latch, 3 Across (Attaches contact block to switch mechanism)
Normally Open Contact Block (for Control Power Switch)
Socket, Guarded, DPDT
Socket, Guarded, 3PDT
Spring Clip Hold Down
Relay, Control 24VDC, DPDT
Relay, Control 120VAC, DPDT
Relay, Control 240VAC, DPDT
Relay, Control 24VDC, 3PDT
Relay, Control 120VAC, 3PDT
Relay, Control 240VAC, 3PDT
Surge suppresser
Digital Boards
Output Module, 24 VDC
Output Module, 24-280 VAC
Input Module, 24 VDC
Input Module, 120 VAC
Input Module, 230 VAC
Fuse, 5 amp, 250 V
Digital Board #1 (Replaces existing board only - no hardware)
Digital Board #2 (Replaces existing board only - no hardware)
Digital Board #2 (Field Upgrade Kit– adds a second digital board)
Description
090.040-M (MAR 12)
Page 111
