OPTIVIEW
CONTROL CENTER
TM
NON-YORK CENTRIFUGAL LIQUID CHILLERS
OPERATION MANUAL
SUPERSEDES: 160.10-O1 (310)
Form 160.10-O1 (418)
OPTIVIEW
CONTROL CENTER RETROFIT KIT
TM
FOR TRANE
LOW PRESSURE
TM
CENTRIFUGAL CHILLERS
Issue Date:
April 27, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YORK OPTIVIEW CONTROL CENTER and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson Controls YORK OPTIVIEW CONTROL CENTER

Summary of Contents for Johnson Controls YORK OPTIVIEW CONTROL CENTER

  • Page 1 OPTIVIEW CONTROL CENTER NON-YORK CENTRIFUGAL LIQUID CHILLERS OPERATION MANUAL SUPERSEDES: 160.10-O1 (310) Form 160.10-O1 (418) OPTIVIEW CONTROL CENTER RETROFIT KIT FOR TRANE LOW PRESSURE CENTRIFUGAL CHILLERS Issue Date: April 27, 2018...
  • Page 2 All wiring must be in accor- dance with Johnson Controls’ published specifications and must be performed only by a qualified electrician. Johnson Controls will NOT be responsible for damage/problems resulting from improper connections to the controls or application of improper control signals.
  • Page 3 Johnson Controls will NOT be responsible Use of gloves and safety glasses are required when for damage due to misuse.
  • Page 4 CHANGEABILITY OF THIS DOCUMENT In complying with Johnson Controls’ policy for con- regarding the applicability of these documents, rig- tinuous product improvement, the information con- ging, lifting, and operating/service personnel should...

  • Page 5: Table Of Contents

    Trend Common Slots Screen ......................... 97 SECTION 3 - OPTIVIEW DISPLAY MESSAGES ....................101 SECTION 4 - PRINTERS ............................119 APPENDIX A - CVHB SCREENS .........................131 APPENDIX B - PROGRAMMABLE SETPOINT VALUES ...................133 APPENDIX C - ANALOG INPUT RANGES (LOW PRESSURE CHILLERS) ............139 JOHNSON CONTROLS...
  • Page 6 FIGURE 41 - Trend Setup Screen ...........................95 FIGURE 42 - Common Slots Screen ........................97 FIGURE 43 - Printers ............................119 FIGURE 44 - Sample Printout (Status)........................123 FIGURE 45 - Sample Printout (Schedule) ......................125 FIGURE 46 - Sample Printout (Sales Order)......................125 JOHNSON CONTROLS...
  • Page 7 FIGURE 51 - Sample Printout (Adaptive Capacity Control Existing Map Points Report) ........128 FIGURE 52 - Sample Printout (Setpoints) ......................129 FIGURE 53 - CVHB Home Screen ........................131 FIGURE 54 - CVHB System Screen ........................131 FIGURE 55 - CVHB Compressor Screen ......................132 FIGURE 56 - CVHB Oil Sump Screen........................132 JOHNSON CONTROLS...
  • Page 8 TABLE 11 - Weigh-Tronix Printer Connections .....................121 TABLE 12 - Seiko Printer Connections .........................121 TABLE 13 - Programmable Setpoint Values ......................133 TABLE 14 - Analog Input Ranges (Low Pressure Chillers) ...................139 TABLE 15 - SI Metric Conversion .........................141 JOHNSON CONTROLS...

  • Page 9: Section 1 - Optiview Retrofit Kit Control Center Introduction

    The operating status, temperatures, Instructions for specific operations are provided on pressures, and other information pertinent to operation many of the display screens. of the chiller are automatically monitored and dis- played on a graphic display. Other displays can be ob- JOHNSON CONTROLS...
  • Page 10 Software updates the Service manual are detailed descriptions of chiller should only be performed by a qualified service tech- features, setup, operations, pre-rotation vane calibra- nician. tion, Smart Freeze, optional hot gas bypass, etc. JOHNSON CONTROLS...
  • Page 11 (0-10VDC, 2-10VDC, 0-20mA or 4-20mA) or Pulse Width Modulation 4. Remote Current Limit Setpoint adjustment (0-10VDC, 2-10VDC, 0-20mA or 4-20mA) or Pulse Width Modulation (PWM) 5. Remote “Ready to Start” Contacts 6. Safety Shutdown Contacts 7. Cycling Shutdown Contacts JOHNSON CONTROLS...
  • Page 12 FORM 160.10-O1 ISSUE DATE: 4/27/2018 THIS PAGE INTENTIONALLY LEFT BLANK. JOHNSON CONTROLS...

  • Page 13: Section 2 - Optiview Operation

    ‘Accept’ symbol and confirms changes made the ‘STOP/RESET’ position. In the middle position, it to the chiller setpoints. is in the ‘RUN’ state. When rotated all the way to the left, the switch is in the ‘START position. JOHNSON CONTROLS...
  • Page 14 If an incorrect password is entered, the user is notified of the failure and prompted again. At this point, the user may retry the password entry or cancel the login attempt. JOHNSON CONTROLS...
  • Page 15 If the value is out of range, the value is not accepted and the user is prompted to re-enter a value. The chiller will begin to operate based on the new programmed value. JOHNSON CONTROLS...
  • Page 16 - Diagnostics - Digital Screen - Diagnostics - VSD Screen • Operations Screen History Screen • History Details Screen • Custom View Screen • (Custom View) Setup Screen • Trend Screen • Trend Setup Screen • Trend Common Slots Screen JOHNSON CONTROLS...

  • Page 17: Home Screen

    This displays the percentage of full load amps utilized Chilled Liquid Temperature – Return by the system. Displays the temperature of the liquid as the liquid en- ters the evaporator. Operating Hours Displays the cumulative operating hours of the chiller. JOHNSON CONTROLS...
  • Page 18 Access Level Required: OPERATOR Use of this key acknowledges a warning condition and Compressor resets the message display associated with the condi- Advances to a detailed view of all the compressor pa- tion. rameters. This includes pre-rotation vane control and calibration. JOHNSON CONTROLS...
  • Page 19 Date/Time, Display Units, Scheduling, Printer Setup, etc. History This screen provides access to a “snapshot” of system data at each of the last ten (10) shutdown conditions. This is particularly useful when troubleshooting chiller system problems. JOHNSON CONTROLS...

  • Page 20: System Screen

    Condenser Liquid Temperature – Return Chilled Liquid Temperature – Return This display indicates the temperature of the condenser liquid as the liquid enters the condenser. This display indicates the temperature of the chilled liquid as the liquid enters the evaporator. JOHNSON CONTROLS...
  • Page 21 0-10VDC or 2-10VDC input in analog remote mode, PWM signal in digital remote mode, MicroGateway interface in ISN (Integrated Systems Network) mode, or a locally programmed value. PROGRAMMABLE None NAVIGATION Home Access Level Required: VIEW Returns the display to the Home screen. JOHNSON CONTROLS...

  • Page 22: Evaporator Screen

    This display indicates the difference between the Evaporator Pressure leaving chilled liquid temperature and the evaporator This display indicates the present refrigerant pressure refrigerant temperature. The evaporator refrigerant in the evaporator. temperature will be represented by the evaporator satu- JOHNSON CONTROLS...
  • Page 23 TEMPERATURE” cycling shutdown. The value is • For example, if the range is programmed for 10°F programmable over a range of 0°F to 70°F (depen- and the locally programmed value of the chilled dant on setpoint temperature) above the chilled liq- JOHNSON CONTROLS...
  • Page 24 Service technicians re- Access Level Required: SERVICE fer to the OptiView Control Center Retrofit Kit - Trane Advances to a sub-screen which allows programming Service Manual (Form 160.10-M1). of load rate. Agitator valves are not used in this ap- plication. JOHNSON CONTROLS...

  • Page 25: Evaporator Options Screen

    As an example, if the LCLTS is 45.0°F, the actual either open or close of the Vane Actuator. Leaving Chilled Liquid Temperature is 58.0°F, and the Load Rate is 3.00 °F/min, the control panel will set the LCLTS to 55.0°F at chiller start and reduce the setpoint JOHNSON CONTROLS...
  • Page 26 Open Pulse Time Access Level Required: VIEW Access Level Required: SERVICE Returns the display to the Evaporator screen. This setpoint determines the length of open pulse time. Example: 1 Sec= means each open pulse will last for 1 Second. JOHNSON CONTROLS...

  • Page 27: Condenser Screen

    This display indicates the refrigerant pressure in the This display indicates the difference between the con- condenser. denser refrigerant temperature and the drop leg refrig- erant temperature. Will only be displayed if the drop leg sensor is enabled. JOHNSON CONTROLS...
  • Page 28 Trane chillers. Should be enabled for Trane ap- plications that have the optional refrigerant sensor kit installed. Purge Type Access Level Required: SERVICE Allows for selection of type of purge system. If a Trane purge unit is utilized, “Skyguard Remote” must be se- lected. JOHNSON CONTROLS...

  • Page 29: Purge Screen

    The LED is not illumi- systems, the valve is energized above 90.0 PSIA and nated when the solenoid is de-energized, draining the de-energizes when the pressure decreases below 80.0 oil from the purge tank. PSIA. For non pump-assisted purge systems, the valve JOHNSON CONTROLS...
  • Page 30 High efficiency (pump assisted) purge systems exhaust above 90.0 PSIA. Non pump-assisted purge systems exhaust above 34.7 PSIA. Trane chillers equipped with a TurboGuard II must be set to “Enabled”. JOHNSON CONTROLS...

  • Page 31: Compressor Screen

    Oil Pressure Oil Sump Temperature Displays the pressure differential between the high Displays the temperature of the oil in the sump. side oil pressure transducer (HOP, located between oil filter output and compressor bearing input) and the low JOHNSON CONTROLS...
  • Page 32 Pre-Rotation Vanes Position (Variable Speed Allows the Vent Line Solenoid to be programmed in an Drive and Hot Gas Option only) energized or de-energized state when the chiller is not running. Trane model chillers must be in the energized state. JOHNSON CONTROLS...
  • Page 33 YORK Service Marketing if this option is in- stalled. SURGE Access Level Required: SERVICE Advances to the SURGE Protection Screen allowing the setup of the surge protection for the unit. Service technicians should refer to OptiView Control Center- Retrofit Kit- Trane Service Manual (Form 160.10-M1) JOHNSON CONTROLS...

  • Page 34: Hot Gas Bypass Screen

    0% (closed) to 100% (fully open). Animation The difference between the leaving chilled liquid tem- indicates valve position as follows: perature and the leaving chilled liquid temperature • 0% to 19% – fully closed. setpoint. • 20% to 39% – 25% open JOHNSON CONTROLS...
  • Page 35 The smaller the value, the more sensitive the control center is to detecting surges. This value is adjustable to tenths (0.1) from 0.3 to 1.3. Three tenths (0.3) is the default setting. Service tech- JOHNSON CONTROLS...

  • Page 36: Pre-Rotation Varies Calibration Screen

    OptiView Control Center Pre-Rotation Vanes Opening (LED) Retrofit Kit - Trane Service Manual (Form 160.10-M1) Indicates the vanes are opening. for an explanation of this function. Pre-Rotation Vanes Closing (LED) Indicates the vanes are closing. JOHNSON CONTROLS...
  • Page 37 Control Center Retrofit Kit - Trane Service Manual (Form 160.10-M1) for an explanation of this function. NAVIGATION Home Access Level Required: VIEW Returns the display to the Home screen. Compressor Access Level Required: VIEW Returns the display to the Compressor screen. JOHNSON CONTROLS...

  • Page 38: Vsd Tuning Screen

    “Head”. This value is calculated by subtracting evaporator pressure from condenser pres- DISPLAY ONLY sure and then dividing by the evaporator pressure. Output Frequency (condenser pressure – evaporator pressure) / evaporator pressure Displays the output frequency reported by the variable speed drive. JOHNSON CONTROLS...
  • Page 39 The value cannot be raised above the maximum allowed frequency. Lower This key puts the VSD frequency control into manual mode and decreases the present command frequency by the defined increment amount. The value will not decrease below one (1) Hz. JOHNSON CONTROLS...

  • Page 40: Surge Protection Screen

    (1 to 5 minutes). When this value compressor VSD adaptive capacity control (ACC) reaches the number of minutes programmed in the board. JOHNSON CONTROLS...
  • Page 41 “SURGE If this setpoint is enabled and the extended run setpoint PROTECTION – EXCESS SURGE”. is disabled, a safety shutdown is performed when the surge window count exceeds the count limit setpoint. JOHNSON CONTROLS...
  • Page 42 “SURGE PROTECTION – EXCESS SURGE” is displayed. There are several exceptions related to VSD and/or hot gas bypass equipped chillers for extended run to oper- ate. See the exceptions listed under “Shutdown”. JOHNSON CONTROLS...

  • Page 43: Oil Sump Screen

    Displays the temperature of the oil in the sump. this differential are out of range, the display field will Sump Oil Pressure (LOP) show XX.X. Displays the low side oil pressure measured by the low oil pressure transducer, located between oil sump and compressor housing). JOHNSON CONTROLS...
  • Page 44 Allows the system prelube time to be adjusted from 15 seconds to 60 seconds. The default setting is 30 sec- onds. Coastdown Time Access Level Required: Service Allows the system coastdown time to be adjusted from 150 seconds to 600 seconds. The default setting is 150 seconds. JOHNSON CONTROLS...

  • Page 45: Electromechanical Starter Screen

    FLA) during the specified pulldown croGateway interface in ISN (Integrated Systems Net- demand time. This value will override the motor cur- work) mode, or a locally programmed value. rent limit value during this time period. This function is JOHNSON CONTROLS...
  • Page 46 Change Setpoint Access Level Required: VIEW Allows user to enter login password to change motor settings. This button is only present at the “View” ac- cess level. JOHNSON CONTROLS...

  • Page 47: Mod "B" Solid State Starter Screen

    Displays the temperatures of the Silicon Controlled grammed locally at the control center in local mode. Rectifier (SCR) assemblies. Pulldown Demand Time Left (Not Shown) Displays the time remaining in the programmed pulldown period. This is only displayed if there is time remaining. JOHNSON CONTROLS...
  • Page 48 Motor Temperature for initiating a shutdown. Service technicians refer to the Solid State Starter MOD “B” – Operation/Service Access Level Required: VIEW Manual (Form 160.00-O2). Advances to the Motor Temperature screen. JOHNSON CONTROLS...

  • Page 49: Variable Speed Drive Screen

    PWM signal in digital remote mode, MicroGateway interface in ISN (Integrated Systems kW Hours Network) mode, or programmed locally at the control Displays the cumulative amount of kilowatts used over center in local mode. time since the count was last reset. JOHNSON CONTROLS...
  • Page 50 Advances to the sub-screen which provides more in- formation about the harmonic filter. Pulldown Demand Time Access Level Required: OPERATOR This setpoint programs the period of time the pulldown demand limit will be in effect after the chiller starts. JOHNSON CONTROLS...

  • Page 51: Variable Speed Drive Details Screen 1

    Trigger SCR Output (LED) returned by the VSD Logic board. Illuminates when the relay controlling the trigger SCR Current Limit Setpoint output is energized. Displays the current limit setpoint programmed by the operator. This value could come from a 0-20mA, JOHNSON CONTROLS...
  • Page 52 If the motor current rises above this value, the pre-rotation vanes will close to reduce cur- rent to this setpoint. This value is adjustable from 30 to 100%, with 100% as the default setting. JOHNSON CONTROLS...

  • Page 53: Variable Speed Drive Details Screen 2

    DC Bus Voltage Displays the current limit setpoint programmed by the operator. This value could come from a 0-20mA, Displays the DC Bus voltage that is reported by the 4-20mA, 0-10VDC or 2-10VDC input in analog re- VSD. JOHNSON CONTROLS...
  • Page 54 This value will override the motor cur- rent limit value during this time period. This function is used to provide energy savings following chiller start- up and is adjustable from 30 to 100%, with 100% as the default setting. JOHNSON CONTROLS...

  • Page 55: Adaptive Capacity Control Details Screen

    ACC board. The surge events detected by the surge Displays the motor current as a percentage of the Full protection feature are not included in this total. Load Amps (FLA) value, as reported by the VSD Log- ic board. JOHNSON CONTROLS...
  • Page 56 Access Level Required: VIEW Returns the display to the VSD screen. ACC Map Report The chiller requests the entire surge map from the ACC. As the map is received, the parameters for each point are printed. JOHNSON CONTROLS...

  • Page 57: Harmonic Filter Details Screen 1

    Displays the DC bus voltage as measured by the har- the operator. This value could come from a 0-20mA, monic filter. 4-20mA, 0-10VDC or 2-10VDC input in analog re- mote mode, PWM signal in digital remote mode, MicroGateway interface in ISN (Integrated Systems JOHNSON CONTROLS...
  • Page 58 Supply Current Total Demand Distortion (L1, L2, L3) Returns the display to the VSD screen. Displays the 3-phase current Total Demand Distortion (TDD) measurements. RMS Supply Current (L1, L2, L3) Displays the 3-phase RMS voltages across each line. JOHNSON CONTROLS...
