System Specifications

ACCESS LINK
Description
Audio output level
(Nominal)
Frequency response
DC power Input
Total harmonic distortion
Wireless communication
Tone control
Audio input
Audio outputs
Audio Link indicator
Device registration
Dimensions (W x H x D)
Weight
FLEXMIKE (1-2)
Description
Earbud lanyard
Wireless communication
Audio distortion
Integrated microphone
Earbud output
Audio input
Volume control
Battery power
Battery life
Charging
34
Wireless audio base station
Line Mode: 316 mV RMS (2V RMS max)
Mic Mode: -40 dB of line mode
120 Hz - 8 kHz
5V/250mA USB-C connector
<1% @ 10W
Access Technology (1.9 GHz)
1 bass/treble control
3.5mm stereo and optical input
3.5mm stereo; 3-pin balanced Euroblock
with volume control
1 LED to indicate microphone is linked
Push button for pod(s), Flexmike(s), Sharemike,
Media Connector
7.6" x 5" x 1.13" (193 x 127 x 29mm)
9.6 oz. (272g)
Pendant-style transceiver
Magnetic clasp with integrated earbud
Access Technology (1.9 GHz)
<1%
Uni-directional electret
3.5mm
USB-C
+/- 6 dB
3.7V LiPo battery pack
8 hours (fully charged)
2 contacts for cradle charging
USB connection
Type C for charging and audio
Power
On/off switch
Registration
Push button for registration with Access Link
Dimensions (L x W x H)
2.9" x 1.1" x 0.7" (74 x 28 x 18mm)
Weight
1.2 oz (34g)
SHAREMIKE
Description
Handheld transceiver
Wireless communication
Access Technology (1.9 GHz)
Audio distortion
<1%
Integrated microphone
Uni-directional electret
Audio input
3.5mm
Battery power
3.7V LiPo battery pack
Battery life
8 hours (fully charged)
Charging
2 contacts for cradle charging
Power
On/off button
Registration
Push button for registration with Access Link
Dimensions (L x W x H)
6.0" x 1.1" x 1.1" (153 x 28 x 28mm)
Weight
2.6 oz (73g)
MEDIA CONNECTOR
Description Wireless audio transceiver
USB power 5V USB-C connector
Wireless communication Access Technology (1.9 GHz)
Tone control 1 bass/treble control
Audio input 3.5mm stereo (x4) with master volume
Audio output
3.5mm stereo (X2) mixed with volume control
Audio Link indicator
1 LED on front panel
Device registration
Push button for Access Link
Dimensions (W x H x D) 7.6" x 5" x 1.13" (193 x 127 x 29mm)
Weight 9.6 oz. (272g)
