6
The keypad must have an address set in it:
• for the INTEGRA 24 or INTEGRA 32 control panel: in the range from 0 to 3,
• for other INTEGRA or INTEGRA Plus control panel: in the range from 0 to 7,
• for the VERSA series control panel: in the range from 0 to 5.
When started with factory default settings, the control panel will support all keypads
connected to the bus, irrespective of the addresses set in them. In all other cases, the
control panel will block operation of the keypads having identical addresses.
If the keypad is connected to the INTEGRA series control panel, the address set in the
keypad determines the numbers to be given to the keypad zones (see the installer manual for
the INTEGRA or INTEGRA Plus control panels).
You can set the address:
• after you connect the factory new keypad to the control panel and start the keypad. You
will be able to use the keypad after you set the address.
• after you started the service mode. The address setting function is available in the service
menu.
• without starting the service mode. When operation of the keypads is blocked and it is
impossible to start the service mode (e.g. the address of the new keypad and the address
of the keypad installed previously are the same), it is the only way to set the address.

3.2.1 Address setting in the factory new keypad

The keypad must be connected to the control panel communication bus.
1. Power on the keypad. The following message will be displayed: "This LCD address (n,
0-x)" [n – keypad address; 0-x – range of supported addresses].
2. Enter the keypad address and tap

3.2.2 Address setting in the service mode

Keypad in the INTEGRA system
Starting the service mode in the INTEGRA system
1. Tap the keypad screen. The user screen will be displayed.
2. Swipe the screen up. The on-screen keypad will be displayed (Fig. 3).
INT-TSH2
. The keypad will restart.
