14
ones offered by SATEL, you must select them while configuring the keypad settings in the
DLOADX program and save them to the memory card.

4.5 Audio files for CHIME signaling

The keypad can use sounds other than the default ones for CHIME signaling. Go to the
DLOADX program to assign different sounds to particular system zones and save the audio
files to the memory card.

4.6 New firmware

If a new version of the keypad firmware is published at www.satel.eu, you can download it
and save it to the card in order to later update the keypad firmware (see "Updating the
keypad firmware" p. 36).

5. Configuring

This section applies to the settings available only to the installer / service technician. The
settings available to the keypad user are described in the user manuals.

5.1 Keypad in the INTEGRA system

To configure the keypad settings you can use:
• DLOADX program: "Structure" window "Hardware" tab "Keypads" branch [keypad
name] (Fig. 13).
• keypad: "Service mode" "Structure" "Hardware" "LCD keypads" "Settings"
[keypad name].
Only the DLOADX program allows you to configure all settings.

5.1.1 Setting description

Shown in square brackets are the names of parameters and options displayed in the keypad.
Keypad
Name – individual name of the keypad (up to 16 characters).
Partitions managed by keypad [Partitions] – partitions which can be armed / disarmed or in
which an alarm may be cleared by using the keypad. These functions are available to the
users who have a suitable authority level and access to those partitions.
Using the service code you can operate all partitions, irrespective of which partitions
are operated by the keypad.
Show alarms of partitions [Alarms] – the keypad can signal burglary alarms from selected
partitions.
Show fire alarms of partitions [Fire alarms] – the keypad can signal fire alarms from
selected partitions.
CHIME signal of zones [Chime zones] – violation of the selected zones is audibly signaled
by the keypad.
Zone disabling chime [Chime bps. zone] – violation of this zone will disable the CHIME
feature.
The zone 256 cannot disable the CHIME feature.
