  • Page 1 Keypad INT-TSH2R Firmware version 2.01 QUICK USER MANUAL int-tsh2r_us_en 03/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
  • Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. Hereby, SATEL sp. z o.o. declares that the radio equipment type INT-TSH2R is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.satel.pl/ce...

  • Page 3: Table Of Contents

    CONTENTS 1. Using the touch screen ...................... 2 2. Using the MIFARE proximity card [INTEGRA] ..............4 ® 3. Screensaver ........................4 Slideshow ........................5 Trigger the panic alarm ....................5 4. User screens ........................6 5. Additional screens ......................7 6.

  • Page 4: Using The Touch Screen

    Ask the installer for instructions on how to use your individually configured keypad. The instructions must include all the changes from the default settings. The installer should also instruct you on how to operate the alarm system by using the INT-TSH2R keypad. 1. Using the touch screen The touch screen displays information about the system status, while allowing you to operate and program the alarm system, as well as control the home automation equipment.
  • Page 5 SATEL INT-TSH2R Tap and hold Tap on an item on the screen and hold for 3 seconds. Swipe up / down Tap the screen and slide your finger up or down to: • swipe the screen up / down (move between the screensaver / user screen / user menu home screen), •...

  • Page 6: Using The Mifare Proximity Card [Integra]

    INT-TSH2R SATEL Swipe right from the edge (return to the previous screen) Tap the screen close to the left edge and slide your finger right to return to the previous screen. This gesture is supported in the user menu and the service menu. You will not be able to exit the service mode by using this gesture.

  • Page 7: Slideshow

    SATEL INT-TSH2R Fig. 1. Screensaver (keypad with factory default settings). The screensaver on a keypad with factory default settings (Fig. 1) shows: • status icons (see p. 8), • date and time, • the icon that indicates where to present the MIFARE card [INTEGRA].

  • Page 8: User Screens

    INT-TSH2R SATEL 4. User screens Fig. 2. User home screen (keypad with factory default settings). When the screensaver or slideshow is displayed, tap the screen to go to the user home screen. If the screensaver has been disabled by the installer, the user home screen will be displayed when the keypad is not in use.

  • Page 9: Additional Screens

    For this reason, the additional screens may be used to display site plans. If pictures other than the ones offered by SATEL are to be displayed, the installer must save them on a memory card and install the card in the keypad.

  • Page 10: Status Bar

    INT-TSH2R SATEL Fig. 3. Screen with a site plan (example). 6. Status bar The status bar is displayed on the top of the user screen and the additional screen. It includes: • status icons, • screen title (optionally, if added by the installer), •...

  • Page 11: Widgets

    Partition state – the widget displays the partition status represented by icons. Zone state – the widget displays the zone status represented by either: – icons selected by SATEL (indicator) – different statuses are displayed, – text messages (text) – messages inform only about normal and violated states, –...

  • Page 12: On-Screen Keypad

    INT-TSH2R SATEL / thermostat [PERFECTA 64 M] state. Tap the widget to change the temperature settings for the thermostatic output / thermostat. This widget is not available in the VERSA system. The thermostatic output / thermostat settings are used to adjust the operating parameters of the ART-200 wireless radiator thermostats.

  • Page 13: User Menu

    SATEL INT-TSH2R 10. User menu Swipe up on the user screen / additional screen to go to the user menu. Since the access to the user menu is code-protected, the keypad will open first. Enter the code. The menu will open immediately if you have already logged in on the user screen.

  • Page 14: Versa / Perfecta 64 M System

    INT-TSH2R SATEL tap to go to the “Others” screen. If the icon is greyed out, the function is unavailable. icon is displayed in the top right corner of the screen. Tap it to exit the user menu. 10.1.2 VERSA / PERFECTA 64 M system Fig.

  • Page 15: Qwerty Keyboard

    SATEL INT-TSH2R 10.2 QWERTY keyboard The QWERTY keyboard is used to enter text. It is displayed e.g. when you search for items on certain screens. Fig. 7. QWERTY keyboard: letter keys mode. The text entered is displayed in the field above the keys.
  • Page 16 INT-TSH2R SATEL PERFECTA 64 M system, it is displayed if you tap the icon on the user menu home screen (it provides access to user functions and service functions). Fig. 8. Terminal in the INTEGRA system. Fig. 9. Terminal in the VERSA / PERFECTA 64 M system.
