4
INT-TSH2
SATEL
Swipe right from the edge (return to the previous screen)
Tap the screen close to the left edge and slide your finger right to return to the previous
screen. This gesture is supported in the user menu and the service menu. You will not be
able to exit the service mode by using this gesture.
3. Installation
Disconnect power before making any electrical connections.
The INT-TSH2 keypad is designed for indoor installation. The place of installation should be
readily accessible to the system users.
1. Open the keypad enclosure (Fig. 1). The enclosure opening tool, shown in the illustration,
is included in the keypad delivery set.
Fig. 1. Opening the enclosure.
2. Place the enclosure base on the wall and mark the location of mounting holes.
3. Drill the holes for wall plugs (screw anchors).
4. Run the wires through the opening in the enclosure base.
