SATEL
2. Tap
3. When identification is completed, information about the devices found will be displayed.
Tap to return to the menu.
DLOADX program
1. Click in the main menu. The "VERSA – Structure" window will be displayed.
2. Click on the "Hardware" tab.
3. Click on the "Expansion modules" branch.
4. Click "Identification". The identification function will start.
5. When identification is completed, a window will be displayed in which you will be asked if
you want to read the data. Click "OK".

4. Memory card

The keypad supports the microSD and microSDHC memory cards. You can save to the
memory card:
• image files to be displayed in the slideshow,
• image files to be displayed on the user screens (protected site plan or background
image),
• audio files to be used for CHIME feature,
• file with a new version of the keypad firmware when the firmware is to be updated.
The memory card should be purchased separately.
To access the memory card slot, open the keypad enclosure. If the alarm system is
working, start the service mode before you open the enclosure.
The memory card slot is marked with the

4.1 Inserting the card

When you insert the card into the slot, make sure to direct the card contacts toward the
display.
Keep pushing the card into the slot until it clicks into place.

4.2 Removing the card

Press the card to release it and remove it from the slot.

4.3 Slideshow

The keypad can run a slideshow of images if you saved the image files to the memory card.
You can do it in the DLOADX program.

4.4 Site plan / background image

It is possible to display images on the user screens. The images can show a plan of the
protected site or serve as a background image. If you want to use images other than the
INT-TSH2
. The identification function will start.
.symbol.
13
