- Page 1 Keypad INT-TSH2R Firmware version 2.01 USER MANUAL – VERSA int-tsh2r_ov_en 03/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 This is a Class A product. In a domestic environment this product may cause radio frequency interference. Hereby, SATEL sp. z o.o. declares that the radio equipment type INT-TSH2R is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.satel.pl/ce...
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ........................3 2. Using the touch screen ...................... 3 3. Screensaver ........................5 Slideshow ........................6 Trigger the panic alarm ....................6 4. User screens ........................6 5. Additional screens ......................8 6. Status bar .......................... 8 7. - Page 4 INT-TSH2R SATEL 10.9.1 Setting the screen brightness ................27 10.9.2 Setting the keypad volume ................27 10.9.3 Setting the auto logout time ................28...
-
Page 5: Introduction
In order to control the alarm system, you can use: • user screens and additional screens created for you by the installer, • user menu created by SATEL. Use the gestures described below. Tap on an item on the screen. - Page 6 INT-TSH2R SATEL Tap and hold Tap on an item on the screen and hold for 3 seconds. Swipe up / down Tap the screen and slide your finger up or down to: • swipe the screen up / down (move between the screensaver / user screen / user menu home screen), •...
-
Page 7: Screensaver
SATEL INT-TSH2R Swipe right from the edge (return to the previous screen) Tap the screen close to the left edge and slide your finger right to return to the previous screen. This gesture is supported in the user menu and the service menu. You will not be able to exit the service mode by using this gesture. -
Page 8: Slideshow
INT-TSH2R SATEL The screensaver on a keypad with factory default settings (Fig. 1) shows: • status icons (see p. 8), • date and time. The installer can add to the screen additional widgets that will indicate the alarm system status (see “Widgets” p. 9). - Page 9 SATEL INT-TSH2R When the screensaver or slideshow is displayed, tap the screen to go to the user home screen. If the screensaver has been disabled by the installer, the user home screen will be displayed when the keypad is not in use.
-
Page 10: Additional Screens
For this reason, the additional screens may be used to display site plans. If pictures other than the ones offered by SATEL are to be displayed, the installer must save them on a memory card and install the card in the keypad. -
Page 11: Widgets
SATEL INT-TSH2R Information about the armed status may be hidden after the time defined by the installer has passed. The trouble information is hidden after arming. The installer defines if the trouble information is hidden after just one of the partitions is armed in any mode or after all partitions are armed in full mode. -
Page 12: Zone State
Zone state The widget displays the zone state represented by either: • icons selected by SATEL (indicator) – different states are displayed, • text messages (text) – messages inform only about normal and violated states, • icons selected by the installer (icon) – only normal and violated states are displayed. -
Page 13: Date/Time
SATEL INT-TSH2R The icons selected by SATEL are described in the table below. Icon Output status deactivated activated “15: Controlled” type output deactivated “15: Controlled” type output activated Date/time The widget displays the date and time in the format specified by the installer. -
Page 14: Analog Value
INT-TSH2R SATEL • tap and hold – tap and hold the widget to turn on an output. The output will remain on as long as you hold the widget. When you take your finger off the widget, the output will be turned off. -
Page 15: User Menu
SATEL INT-TSH2R 10. User menu Swipe up on the user screen / additional screen to go to the user menu. Since the access to the user menu is code-protected, the keypad will open first. Enter the code. The menu will open immediately if you have already logged in on the user screen. -
Page 16: Qwerty Keyboard
INT-TSH2R SATEL 10.2 QWERTY keyboard The QWERTY keyboard is used to enter text. It is displayed when you search for items on certain screens. Fig. 6. QWERTY keyboard: letter keys mode. The text entered is displayed in the field above the keys. -
Page 17: Partitions" Screen
SATEL INT-TSH2R Fig. 7. QWERTY keyboard: number keys mode. 10.3 “Partitions” screen On this screen you can see the list of the partitions that you can operate by means of the keypad. The partitions are represented by icons that indicate the partition state. The icons are the same as the ones used by the “Partition state”... -
Page 18: Arming
INT-TSH2R SATEL The icons in the top right corner allow you to: tap to clear alarm. tap to terminate the exit delay. tap to filter the partition list (see “Filtering the partition list” p. 17). tap to search for partition/partitions (see “Searching for partitions” p. 17). -
Page 19: Filtering The Partition List
SATEL INT-TSH2R 10.3.3 Filtering the partition list 1. Tap the icon. The buttons with filtering criteria will appear. 2. Tap the buttons with the filtering criteria that you want to use. You can tap any number of buttons. 3. Tap the button with the icon. -
Page 20: Zone Inhibiting
INT-TSH2R SATEL The icon displayed in front of the partition name allows you to: tap to hide the list of zones that belong to the partition. tap to show the list of zones that belong to the partition. Information about how many zones are selected is shown in brackets next to the partition name ([number of selected zones]/[number of zones]). -
Page 21: Zone Unbypassing
SATEL INT-TSH2R 10.4.3 Zone unbypassing 1. Tap the zone you want to unbypass. The button with the icon will appear at the bottom of the screen. 2. If you want unbypass several zones, tap each zone one by one. 3. Tap the button with the icon. -
Page 22: Output Control
INT-TSH2R SATEL The icon displayed above the list of outputs allows you to: tap to hide the list of outputs. tap to show the list of outputs. Information about how many outputs are activated is shown in brackets above the list of outputs ([number of activated outputs]/[number of outputs]). -
Page 23: Terminal
SATEL INT-TSH2R 10.8 Terminal The terminal allows you to enter data and configure the settings in the same way as from the LCD keypad with text menu. To close the terminal, tap to the right of the terminal (this icon is available, if no function is displayed by the terminal). -
Page 24: Using The Terminal
INT-TSH2R SATEL Functions of keys arm the system in the full mode if the system is disarmed and there is no alarm condition (enter the code and tap disarm the system and clear the alarm if the system is armed and/or there is... - Page 25 SATEL INT-TSH2R 2. Select the arming mode (tap one of the keys: - full arming; - day arming; - night arming). 3. Enter the code. 4. Tap or tap again the key corresponding to the selected arming mode. 5. In the selected partition, the arming procedure will begin.
- Page 26 INT-TSH2R SATEL Disarming and alarm clearing in selected partition 1. Select the partition which is to be disarmed and/or where alarm is to be cleared (tap one of the keys: - partition 1; - partition 2). 2. Tap 3. Enter the code.
- Page 27 SATEL INT-TSH2R Navigating through the menu and running functions Using the arrow keys 1. Using the keys, find the required submenu or function. The currently selected submenu or function is indicated by the cursor on the left. 2. Tap to open a submenu or run a function (use the key to go back to the previous menu/submenu).
-
Page 28: Keypad" Screen
INT-TSH2R SATEL Entering decimal and hexadecimal values To enter digits, use the number keys. To enter characters from A to F, use the keys (keep tapping the key until the required character appears). Entering names Keep tapping the key until the required character appears. Long tap the key to display the digit assigned to it. - Page 29 SATEL INT-TSH2R tap to format the memory card. tap to set the auto logout time (see: “Setting the auto logout time” p. 28). in the top right corner of the screen to return to the previous screen. 10.9.1 Setting the screen brightness Tap the “Brightness”...
- Page 30 INT-TSH2R SATEL volume of the alarm sounds. Tap the button with the icon to confirm changes. Tap the button with the icon to cancel changes. 10.9.3 Setting the auto logout time Tap the „Auto logout” function. The buttons and the slider will appear at the bottom of the screen.
