State follow input – if you select this option, the widget will indicate the state based on
the zone state (two icons will be used).
State follow output – if you select this option, the widget will indicate the state based on
the output state (two icons will be used).
Zone – widget indicates the state of this zone if you selected the "State follow input" option.
Select the zone whose state will be affected by the macro command (e.g. zone that
supervises the operation of a device turned on / off by a macro command).
Output – widget indicates the state of this output if you selected the "State follow output"
option. Select the output whose state will be affected by the macro command (e.g. the
"21: Armed status" type output which turns on after partition is armed).
Icon – pictogram used to represent a macro command on the screen. Click
a pictogram.
Off – pictogram used to represent a macro command on the screen when the widget
indicates the inactive state. Click
Active – pictogram used to represent a macro command on the screen when the widget
indicates the active state. Click
Commands list – commands assigned to the currently highlighted macro command. The
and buttons allow you to change the order of commands (moving the selected
command up and down).
Add – click to add to the list a new command selected in the "Command" field.
Change – click to save the changes to the command settings that were made after adding
the command to the list (otherwise, the changes will not be saved).
Delete – click to remove the highlighted command from the list.
Command – function that you can assign to the macro command. Click
list of available functions, then click on the function that you want to assign to the macro
command.
The "KNX telegram" and "KNX telegram (v2)" functions allow you to control the KNX
system if the INT-KNX or the INT-KNX-2 module is connected to the control panel.
List – fields in this table represent the system elements (partitions / zones / outputs) that can
be controlled by the function. The numbers of the fields in the table correspond to the
numbers of the elements in the system. The color of the field indicates:
orange – function controls this system element,
white – function does not control this system element.
Double-click on the field to change its color.
Depending on the selected function:
Arming – select the partitions to be armed and define the arming mode (successive clicks
on the field). The digit inside the field indicates:
0 – fully armed,
1 – fully armed + bypasses,
2 – armed without interior,
3 – armed without interior and without entry delay.
