Satel INT-TSH2 Installer Manual page 19

SATEL
Show arm messages [Show arm] – if this option is enabled, the keypad displays the arming
message. If this option is disabled, the arming message is not displayed.
Quick control [Control (8#)] – if this option is enabled, the user can control the outputs by
using widgets without entering the user code.
Zone
in LCD keypad – if you select this option, the keypad zone will be supported.
Not used – if you select this option, the keypad zone will not be supported.
Auto-backlight
Entry delay in part. – if you select this option, the keypad will be woken up when the entry
delay countdown begins in a selected partition.
viol. of zone – if you select this option, the keypad will be woken up when a selected zone is
violated.
no – if you select this option, the keypad will be woken up only when the user taps the
screen.
Wake-up – the way the keypad will respond to the wake-up (when the user taps the screen
or a specified event occurs in the system):
Screensaver – screensaver will be displayed.
User screen – user home screen will be displayed.
Screensaver – if this option is enabled, the keypad screen is turned off after 10 minutes of
inactivity.
Tamper signaled in part. [Tamper in part.] – partition where alarm will be triggered in the
event of keypad tamper, triggering the alarm from keypad etc.
Keypad data
Go to this tab to configure the settings that are stored in the keypad. These settings can only
be configured in the DLOADX program.
The buttons located on the bottom of the window apply to all settings that are stored in the
keypad.
Read – click to read data from the keypad.
Write – click to write data to the keypad.
Quit – click to cancel the reading / writing of data.
Reset – click to restore the factory default settings of the keypad (this command applies to
the settings presented in the "Keypad data" tab).
Export to file – click to export the keypad data to a file.
Import from file – click to import the keypad data from a file.
Before you make any changes, click on the "Read" button, and after you make the
changes, click on the "Write" button. The settings stored in the keypad are not read /
written after you click on
INT-TSH2
/ in the main menu.
17
