Alarm clearing – select the partitions in which alarm is to be cleared.
Bypass zones – select the zones which are to be inhibited.
Unbypass zones – select the zones which are to be unbypassed.
Outputs ON – select the outputs to be activated.
Outputs OFF – select the outputs to be deactivated.
Change outputs state – select the outputs whose state is to be changed.
The partitions must be controlled by user code.
The zones must not have the "Bypass disabled" option enabled.
The outputs must be the "24: MONO Switch", "25: BI Switch", "105: Shutter up",
"106: Shutter down" or "Remote switch" type (they do not need to be assigned to any
group of outputs).
KNX telegram – if you select this function, configure the following parameters of the KNX
telegram:
Module INT-KNX – INT-KNX module to send the telegram.
Group address – group address that will be inserted in the telegram.
Type – telegram type.
Value – value that will be inserted in the telegram (parameter available for some types of
the telegram).
Priority – telegram priority (if two elements of the bus start transmitting simultaneously,
the telegram with higher priority will be sent first).
KNX telegram (v2) – if you select this function, configure the following parameters related to
setting the value of the KNX communication object:
Module INT-KNX – INT-KNX-2 module in which the value is to be set.
Macro Command – name of the "Virtual (macro)" type object, defined in the INT-KNX-2
module.
Data type – size and meaning of the communication object data defined in INT-KNX-2
module for selected object.
Value – value to be set (if the type of data provides for sending a sequence of characters,
you can enter up to 13 characters).
Creating a macro command
1. Click on the "Read" button to read the macro command settings from the keypad.
2. Click on the "New macro" button. A new macro command will appear in the list.
3. Enter a name for the new macro command.
4. If the user is to run the micro command without entering the code, enter the user code.
You can create an additional user whose code will be used for this purpose. The user
must be granted a suitable authority level in order to be able to run the functions that you
want to assign to the macro command.
5. Specify if the widget displayed in the keypad is to show the state:
– select the "No state indication" option if the widget is not to show the state,
– select the "State follow input" or "State follow output" option if the widget is to show the
state.
6. If you selected the "State follow input" / "State follow output" option, select the
zone / output whose state is to control the widget icons.
