Satel INT-TSH210 Quick Installation Manual

INT-TSH210
Keypad
Full manual is available on
website and download the manual.
The device should be installed by qualified personnel.
Changes, modifications or repairs not authorized by the manufacturer shall void your
rights under the warranty.
Disconnect power before making any electrical connections.
Tips for installation
•
The keypad should be installed indoors, in spaces with normal air humidity.
•
Do not install the keypad outdoors.
•
The place of installation should be readily accessible to the system users.
•
To make the connection, use an unshielded non-twisted cable. If you use the twisted-pair type of
cable, remember that CLK (clock) and DTA (data) signals must not be sent through one twisted-
pair cable.
•
The wires must be run in one cable.
•
The length of cable must not exceed 300 m.
•
The keypad can be powered from the control panel, from an expander with power supply or from
an additional power supply.
Installation
Wall mounting
1. Install the large tamper insert (Fig. 1-I) on the bracket (Fig. 2).
2. Place the bracket against the wall and mark the location of the mounting holes (Fig. 3) and the
hole in the tamper insert (the
3. Drill the holes in the wall for wall plugs (anchors) in the marked spots. Use wall plugs specifically
intended for the mounting surface (different for concrete or brick wall, different for plaster wall,
etc.).
4. Run the cables through the hole in the bracket (Fig. 3).
5. Secure the bracket to the wall with screws.
6. Secure the tamper insert to the wall with a screw.
7. Screw the wires to the keypad terminals (see "Connecting").
8. Mount the keypad on the bracket (Fig. 4).
Quick installation guide
www.satel.pl
symbol in Fig. 3).
. Scan the QR code to go to our
int-tsh210_sii_en 03/25
