The INT-TSH2 keypad allows you to operate and program control panels of the INTEGRA
series (firmware version 1.20 or newer) and the VERSA series (firmware version 1.06
or newer).

1. Features

• Touch screen:
– diagonal: 7",
– resolution: 1024 x 600,
– color depth: 24 bpp.
• Customizable user screens.
• Widget-based operation of the alarm system.
• Alarm system control by means of macro commands to facilitate the running of functions.
• Possibility to display plans of the protected site.
• Intuitive icon-based user menu.
• Customizable screensaver.
• Possibility to display a slideshow.
• Built-in reader of microSD memory cards.
• Built-in speaker for signaling.
• 2 programmable hardwired zones (supported by the INTEGRA series control panels):
– support for NO and NC type detectors, as well as roller shutter and shock detectors,
– support for EOL, 2EOL and 3EOL configuration (3EOL for the INTEGRA Plus control
panels),
– programmable end-of-line resistor value.
• Tamper protection against enclosure opening and removal from mounting surface.

2. Using the touch screen

Use the gestures described below.
Tap
Tap on an item on the screen.
