LEC-iMX8M plus User's Guide 1.0
SGET SMARC Rev 2.1

Introduction

1.1 The SMARC Formfactor

The SMARC ("Smart Mobility ARChitecture") is a versatile small form factor computer on Module definition targeting applications that require low power,
low costs, and high performance. The Modules will typically use ARM SOCs similar or the same as those used in many familiar devices such as tablet
computers and smart phones. Alternative low power SOCs and CPUs, such as tablet oriented X86 devices and other RISC CPUs may be used as well. The
Module power envelope is typically under 6W.
Two Module sizes are defined: 82 mm x 50 mm and 82 mm x 80 mm.
The Module PCBs have 314 edge fingers that mate with a low profile 314 pin 0.5 mm pitch right angle connector (the connector is sometimes identified
as a 321 pin connector, but 7 pins are lost to the key).
The Modules are used as building blocks for portable and stationary embedded systems. The core CPU and support circuits, including DRAM, boot flash,
power sequencing, CPU power supplies, GBE and a single channel LVDS display transmitter are concentrated on the Module. The Modules are used with
application specific Carrier Boards that implement other features such as audio CODECs, touch controllers, wireless devices, etc. The modular approach
allows scalability, fast time to market and upgradability while still maintaining low costs, low power and small physical size.
SMARC module and carrier specifications are available online at:
https://www.sget.org/standards/smarc.html
Page 8
copyright © 2021 ADLINK Technology Inc.
