LEC-iMX8M plus User's Guide 1.0
P-Pin
Primary (Top) Side
P125
BOOT_SEL2#
P126
RESET_OUT#
P127
RESET_IN#
P128
POWER_BTN#
P129
SER0_TX
P130
SER0_RX
P131
SER0_RTS#
P132
SER0_CTS#
P133
GND
P134
SER1_TX
P135
SER1_RX
P136
SER2_TX
P137
SER2_RX
P138
SER2_RTS#
P139
SER2_CTS#
P140
SER3_TX
P141
SER3_RX
Note : DSI0 is pinshared with LVDS0
Page 19
S-Pin
Secondary (Bottom) Side
S126
LVDS0_0- / eDP0_TX0- / DSI0_D0-
S127
LCD0_BKLT_EN
S128
LVDS0_1+ / eDP0_TX1+ / DSI0_D1+
S129
LVDS0_1- / eDP0_TX1- / DSI0_D1-
S130
GND
S131
LVDS0_2+/eDP0_TX2+/ DSI0_D2+
S132
LVDS0_2- / eDP0_TX2- / DSI0_D2-
S133
LCD0_VDD_EN
S134
LVDS0_CK+/eDP0_AUX/ DSI0_CLK+
S135
LVDS0_CK-/eDP0_AUX- / DSI0_CLK-
S136
GND
S137
LVDS0_3+ / eDP0_TX3+ / DSI0_D3+
S138
LVDS0_3- / eDP0_TX3- / DSI0_D3-
S139
I2C_LCD_CK
S140
I2C_LCD_DAT
S141
LCD0_BKLT_PWM
S142
GPIO12
copyright © 2021 ADLINK Technology Inc.
P-Pin
Primary (Top) Side
P142
GND
P143
CAN0_TX
P144
CAN0_RX
P145
CAN1_TX
P146
CAN1_RX
P147
VDD_IN
P148
VDD_IN
P149
VDD_IN
P150
VDD_IN
P151
VDD_IN
P152
VDD_IN
P153
VDD_IN
P154
VDD_IN
P155
VDD_IN
P156
VDD_IN
SGET SMARC Rev 2.1
S-Pin
Secondary (Bottom) Side
S143
GND
S144
eDP0_HPD / DSI0_TE
S145
WDT_TIME_OUT#
S146
PCIE_WAKE#
S147
VDD_RTC
S148
LID#
S149
SLEEP#
S150
VIN_PWR_BAD#
S151
CHARGING#
S152
CHARGER_PRSNT#
S153
CARRIER_STBY#
S154
CARRIER_PWR_ON
S155
FORCE_RECOV#
S156
BATLOW#
S157
TEST#
S158
GND
