LEC-iMX8M plus User's Guide 1.0
SGET SMARC Rev 2.1

4. Pinout and Signal Descriptions

4.1 Pin Summary

The below table is a comprehensible list of all signal pins on the MXM 3 connector in the standard specification SMARC 2.1.
Those signals not supported on LEC-iMX8M plus are strikethrough STRIKETHROUGH
P1
P74
P75
P156
S156
S76
S75
S1
Key
Key
Page 16
copyright © 2021 ADLINK Technology Inc.
