LEC-iMX8M plus User's Guide 1.0
4.3.2.1
HDMI
Name
Pin #
Description
HDMI_D2+
P92
HDMI port, differential pair data lines
HDMI_D2-
P93
HDMI_D1+
P95
HDMI_D1-
P96
HDMI_D0+
P98
HDMI_D0-
P99
HDMI_CK+
P101
HDMI port, differential pair clock lines
HDMI_CK-
P102
HDMI_CTRL_CK
P105
I2C_CLK line dedicated to HDMI
HDMI_CTRL_DAT
P106
I2C_DAT line dedicated to HDMI
HDMI_HPD
P104
HDMI Hot plug active high detection
signal that serves as an interrupt
request
Page 25
I/O
I/O
Power
Type
Level
Domain
O TMDS
Runtime
HDMI
O TMDS
Runtime
HDMI
O OD
1.8V
Runtime
COMS
I/O OD
1.8V
Runtime
COMS
I
1.8V
Runtime
CMOS
copyright © 2021 ADLINK Technology Inc.
PU /
Comments
PD
PU 2.2
Level shifter FET and 5V PU resistor shall be placed
between the module and the HDMI connector.
PU 2.2K
Level shifter FET and 5V PU resistor shall be placed
between the module and the HDMI connector.
PD 1M
Module must tolerate high level in stand-by mode
SGET SMARC Rev 2.1
