Directed Directechs DS4+ Installation Manual page 51

Wire Information
Function Color
Mercury Mariner Hybrid 2006-2007
RX Red/Black
TX Brown/Orange
12V Red
Ignition Lt. Green/Violet
Starter Tan/Blue
Accessory Black/Lt. Green
Keysense Black/Pink
HS CAN High White
HS CAN Low Black
Driver Door Trigger Lt. Green/Black
Parking Lights Brown
Hood Trigger Violet/Orange
Lock
Pink/White
Unlock
Factory Disarm Dk. Blue/Green
Brake Lt. Green
Passenger Door Trigger Dk. Blue
Driver Rear Door Trigger Violet/Lt. Green
Passenger Rear Door Trigger Pink/Lt. Blue
Mercury Mariner Hybrid 2008-2010
RX Violet/Gray
TX Yellow/Orange
12V Blue/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
Parking Lights Violet/White
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Passenger Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Lock Blue/Green
Unlock Yellow/Violet
Brown (lift gate);
Trunk Release Brown/Yellow
(glass)
Brake Violet/White
51
Pin Polarity Location
4 Data (PATS) connector Type 2.
3 Data (PATS) connector Type 2.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
21 N. Closed Drivers kick panel door harness.
19 (+) SJB (Smart Junction Box) passenger side center console
5 N. Closed SJB passenger side center console or driver kick panel.
MUX
SJB passenger side center console or drivers kick panel, (-)
22
trigger thru 1000Ω resistor.
(-)
3 (-) SJB under drivers dash or driver kick panel.
14 (+) SJB passenger side center console or driver kick panel.
20 N. Closed SJB passenger side center console.
Required ONLY when enabling the security features during
19 N. Closed
module flashing.
18 N. Closed
See Tech Tip 1921 at www.directechs.com.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
20 (+) Driver kick panel or SJB (Smart Junction Box) passenger side
center console.
6 Data OBDII.
14 Data OBDII.
14 N. Closed Driver kick panel or SJB passenger side center console.
2 N. Closed SJB under drivers dash or passenger side center console.
Required ONLY when enabling the security features during
3 N. Closed
module flashing.
15 N. Closed
See Tech Tip 1921 at www.directechs.com.
17 (-) Driver kick panel or SJB passenger side center console.
4 (-) Driver kick panel or SJB passenger side center console.
7 or
(-) Driver kick panel or SJB passenger side center console.
20
40 (+) SJB passenger side center console.
Connector Information
Color
Green
Green
Black
Black
Black
Black
Black
Black
Black
Gray
Brown
Black
Gray
Gray
Black
Gray
Gray
Gray
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Gray
Gray
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
7 B
7 B
7 B
7 B
7 B
16 C
16 C
32 D
32 I
32 I
32 I
32 I
32 I
32 I
32 I
32 I
4 A
4 A
7 B
7 B
7 B
7 B
7 B
32 I
16 C
16 C
26 I
32 I
32 I
32
26 I
26 I
26 I
52 I
DS4+ FORD1
