Directed Directechs DS4+ Installation Manual page 43

Wire Information
Function Color
Ford Mustang (SA) 2011-2012
RX Gray/Orange
TX White/Lt. Green
12V Red
Ignition White/Yellow
Starter Dark Green
Accessory Black/Pink
Keysense Lt. Green/Violet
Parking Lights Black/Lt. Green
Parking Lights Ground Black
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Driver Door Trigger Lt. Green/Black
Lock White/Violet
Unlock Blue/Green
Factory Disarm Lt. Blue/Black
Hood Trigger Violet/Orange
Brake Lt. Green
Trunk Release White/Violet
Passenger Door Trigger White
Ford Sport Trac 2007-2010
RX Yellow/Gray
TX Yellow/Orange
12V Violet/Red
Ignition White/Orange
Starter White/Blue
Accessory Violet/Green
Keysense Blue/Gray
HS CAN High White/Blue
HS CAN Low White
Parking Lights Blue/White
Brake Violet/White
Driver Door Trigger Green/Violet
Lock Gray/Yellow
Unlock Violet/Gray
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
43
Pin Polarity Location
3 Data (PATS) connector Type 4.
4 Data (PATS) connector Type 4..
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
5 (-) Headlight switch.
See Tech Tip 1096 at ww.directechs.com
7 Cut
6 Data OBDII.
14 Data OBDII.
2 N. Closed Passenger SJB (Smart Junction Box) or drivers kick.
3 (-) Passenger SJB or drivers kick.
1 (-) Passenger SJB or drivers kick.
9 (-) Passenger SJB or drivers kick.
15 N. Closed Passenger SJB.
16 (+) Passenger SJB or brake switch.
13 (-) Passenger SJB or trunk release switch.
2 N. Closed Passenger SJB or drivers kick.
Required ONLY when enabling the security features during
module flashing.
See Tech Tip 1921 at www.directechs.com.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4..
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
11 (+) Drivers SJB (Smart Junction Box) or drivers kick.
15 (+) Drivers SJB or Brake switch.
17 N. Closed Drivers SJB or drivers kick.
27 (-) Drivers SJB or drivers kick.
26 (-) Drivers SJB or drivers kick.
19 N. Closed Drivers SJB or drivers kick.
Required ONLY when enabling the security features during
20 N. Closed
module flashing.
21 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Brown
Brown
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Brown
Brown
Black
Black
Black
Black
Black
Black
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
7 B
7 B
7 B
7 B
7 B
10 H
10 H
16 C
16 C
26 P
26 P
26 P
26 P
52 P
36 P
52 P
26 P
4 A
4 A
7 B
7 B
7 B
7 B
7 B
16 C
16 C
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
DS4+ FORD1
