Wire Information
Function Color
Mercury Mountaineer 2002-2005
Brake Tan/Black
RX Gray/Orange
TX White/Lt. Green
12V Yellow
Ignition Red/Lt. Green
Starter Red
Accessory Dk. Green/
Lt. Green
Keysense Lt. Green/Violet or
Black/Lt. Green
Parking Lights Brown
HS CAN High - (2004-2005) Tan/Yellow
HS CAN Low - (2004-2005) Red/Yellow
Driver Door Trigger Yellow/Black
Lock Pink/Yellow
Unlock Pink/Lt. Green
Trunk Release Pink/Orange
Driver Rear Door Trigger Lt. Green/Yellow
Passenger Door Trigger Gray/Red
Passenger Rear Door Trigger Pink/Lt. Blue
Mercury Mountaineer 2006-2007
RX Violet/Gray
TX Yellow/Orange
12V Violet/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
HS CAN High White/Blue
HS CAN Low White
Parking Lights Blue/White
Driver Door Trigger Green/Violet
Lock Gray/Yellow
Unlock Violet/Gray
Trunk/Hatch Release Brown
Brake Violet/White
Passenger Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
54
Pin Polarity Location
1 (+) Brake pedal switch.
4 Data (PATS) connector Type 2.
3 Data (PATS) connector Type 2.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
12 (+) Headlight switch.
6 Data OBDII.
14 Data OBDII.
N/A N. Closed Drivers kick panel harness to rear
N/A (-) Driver kick panel door harness.
N/A (-) Driver kick panel door harness.
N/A (-) Harness going into rear hatch.
N/A N. Closed Drivers rear door harness.
Required ONLY if using Directed Digital Systems security
features
See Tech Tip 1921 at www.directechs.com.
N/A N. Closed Passenger kick panel door harness.
Required ONLY when enabling the security features during
module flashing.
See Tech Tip 1921 at www.directechs.com.
N/A N. Closed Passenger rear door harness.
Required ONLY when enabling the security features during
module flashing.
See Tech Tip 1921 at www.directechs.com.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
11 (+) SJB (Smart Junction Box) under drivers dash or driver kick panel.
17 N. Closed SJB under drivers dash or driver kick panel.
27 (-) SJB under drivers dash or driver kick panel.
26 (-) SJB under drivers dash or driver kick panel.
29 (-) SJB under drivers dash or driver kick panel.
15 (+) SJB under drivers dash or brake switch.
19 N. Closed SJB under drivers dash or driver kick panel.
Required ONLY when enabling the security features during
20 N. Closed
module flashing.
21 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Black
Green
Green
Black
Black
Black
Black
Black
Gray
Black
Black
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Black
Black
Black
Black
Black
Black
Black
Black
Black
Brown
Black
Black
Black
Black
Brown
Black
Black
Black
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
2 K
4 A
4 A
7 B
7 B
7 B
7 B
7 B
12 H
16 C
16 C
N/A F
N/A F
N/A F
N/A N/A
N/A S
N/A P
N/A T
4 A
4 A
7 B
7 B
7 B
7 B
7 B
16 C
16 C
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
DS4+ FORD1
