Directed Directechs DS4+ Installation Manual page 22

Wire Information
Function Color
Lincoln Navigator 2002
RX Gray/Orange
TX White/Lt. Green
Brake Green
Parking Lights Brown
12V Lt. Green/Violet
Ignition Black/Yellow
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
Accessory 3 Red/Black
Driver Door Trigger Black/Yellow
Lock Pink/Yellow
Unlock Pink/Lt. Green
Passenger Door Triggers Black/Pink
Driver Rear Door Trigger Black/Lt. Blue
Passenger Rear Door Trigger Black/White
HS CAN High N/A
HS CAN Low N/A
Lincoln Town Car 2003-2004
Brake Lt. Green
RX Gray/Orange
TX White/Lt. Green
Keysense Black/Pink
12V Yellow or
Lt. Green/Violet
Ignition White/Yellow
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
Accessory 3 Pink/Black
Hood Trigger Violet/Orange
Driver Door Trigger Dark Blue
Parking Lights Brown
Lock Pink/Yellow
Unlock Pink/Green
Trunk Release Red
Passenger Door Triggers Black/Orange
HS CAN High N/A
HS CAN Low N/A
22
Pin Polarity Location
4 Data (PATS) connector Type 1.
3 Data (PATS) connector Type 1.
2 (+) Trailer connector above gas pedal.
5 (+) Headlight switch or drivers kick panel.
B3 (+) Ignition switch.
I1 (+) Ignition switch.
STA (+) Ignition switch.
A4 (+) Ignition switch.
A1 (+) Ignition switch.
A2 (+) Ignition switch.
N/A (-) GEM (Generic Electronic Module) high in drivers kick panel.
N/A (-) GEM high in drivers kick panel.
N/A (-) GEM high in drivers kick panel.
N/A (-)
GEM high in drivers kick panel.
N/A (-) Required ONLY when enabling the security features during module
flashing.
N/A (-)
N/A N/A N/A
N/A N/A N/A
2 (+) Brake pedal switch or LCM (Lighting Control Module) right of
steering column.
3 Data (PATS) connector Type 4.
4 Data (PATS) connector Type 4.
5 (+) Bottom of steering column.
B3 (+) Ignition switch.
I1 (+) Ignition switch.
STA (+) Ignition switch.
A2 (+) Ignition switch.
A1 (+) Ignition switch.
A3 (+) Ignition switch.
2 Data LCM right of steering column.
4 (-) DDM (Drivers Door Module) in drivers door.
10 (+) LCM right of steering column.
N/A (-) Drivers kick panel.
N/A (-) Drivers kick panel.
Red 5-wire Drivers kick panel junction block.
N/A (-) Drivers kick panel or DDM in drivers door.
Required ONLY when enabling the security features during module
flashing.
N/A N/A N/A
N/A N/A N/A
Connector Information
Color
Green
Green
Gray
Gray
Black
Black
Black
Black
Black
Black
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Black
Green
Green
White
Black
Black
Black
Black
Black
Black
White
Gray
Black
N/A
N/A
N/A
N/A
N/A
N/A
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
6 E
10 F
15 B
15 B
15 B
15 B
15 B
15 B
N/A H
N/A H
N/A H
N/A H
N/A H
N/A H
N/A N/A
N/A N/A
2 D
4 A
4 A
8 K
15 B
15 B
15 B
15 B
15 B
15 B
16 E
16 M
26 E
N/A C
N/A C
N/A C
N/A M
N/A N/A
N/A N/A
DS4+ FORD1
