Directed Directechs DS4+ Installation Manual page 30

Wire Information
Function Color
Ford Edge 2011
RX Violet/Gray
TX Yellow/Orange
Power Lift gate Gray/Yellow
12V Green/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
Parking Lights Yellow/Blue
HS CAN High White/Blue
HS CAN Low White
Hood Trigger Blue/Orange
Driver Door Trigger Green/Violet
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Lock Blue/Green
Unlock Yellow/Violet
Brake Violet/White
Ford Escape 2005-2007
RX Red/Black
TX Brown/Orange
12V Red
Ignition Lt. Green/Violet
Starter Tan/Blue
Accessory Black/Lt. Green
Keysense Black/Pink
HS CAN High - (2005-2007) White
HS CAN Low - (2005-2007) Black
Hood Trigger Violet/Orange
Driver Door Trigger Lt. Green/Black
Lock
Pink/White
Unlock
Factory Disarm Dk. Blue/Lt. Green
Parking Lights Brown
Brake Lt. Green
Passenger Door Trigger Dk. Blue
Driver Rear Door Trigger Violet/Lt. Green
Passenger Rear Door Trigger Pink/Blue
30
Pin Polarity Location
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
6 (-) Power lift gate switch.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 (+) BCM in drivers kick panel.
6 Data OBDII.
14 Data OBDII.
2 N. Closed BCM in drivers kick panel.
9 N. Closed BCM in drivers kick panel.
5 N. Closed BCM in drivers kick panel.
Required ONLY when enabling the security features during
20 N. Closed
module flashing.
21 N. Closed
See Tech Tip 1921 at www.directechs.com.
3 (-) BCM in drivers kick panel.
8 (-) BCM in drivers kick panel.
28 (+) Brake switch or BCM in drivers kick.
4 Data (PATS) connector Type 2.
3 Data (PATS) connector Type 2.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
5 N. Closed SBJ (Smart Junction Box) in passenger side center console.
21 N. Closed SBJ in passenger side center console.
MUX
SJB passenger side center console or drivers kick panel, (-)
22
trigger thru 1000Ω resistor.
(-)
3 (-) SJB passenger side center console or drivers kick panel.
19 (+) SBJ in passenger side center console.
14 (+) SJB passenger side center console or brake switch.
20 N. Closed SBJ in passenger side center console.
Required ONLY when enabling the security features during
19 N. Closed
module flashing.
18 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Green
Green
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Gray
Brown
Black
Gray
Gray
Gray
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
6 R
7 B
7 B
7 B
7 B
7 B
10 D
16 C
16 C
26 D
26 D
26 D
26 D
26 D
26 D
26 D
52 D
4 A
4 A
7 B
7 B
7 B
7 B
7 B
16 C
16 C
32 I
32 I
32 I
32 I
32 I
32 I
32 I
32 I
32 I
DS4+ FORD1
