Directed Directechs DS4+ Installation Manual page 11

Wire Information
Function Color
Ford Crown Victoria 2008-2011
RX Gray/Orange
TX White/Lt. Green
Brake Lt. Green/Red
12V Lt. Green/Violet
Ignition Violet/Orange
Starter Dark Green
Accessory Gray/Yellow or
Black/Lt. Green
Accessory 1 Gray/Yellow
Accessory 2 White/Violet
Keysense Gray/Yellow or
Black/Pink
Parking Lights Brown
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Passenger Door Triggers Black/Orange
Driver Door Trigger Dk. Blue
Trunk Release White/Violet
Lock Pink/Yellow
Unlock Pink/Lt. Green
Ford Escape 2001-2004
RX Red/Black
TX Brown/Orange
Red/ Lt. Blue or
12V
Green/Red
Ignition Lt. Green/Violet
Starter Tan/Blue
Accessory Black/Lt. Green
Keysense Black/Pink
Hood Trigger Violet/Orange
Driver Door Trigger Violet/Lt. Green
Lock
Pink/White
Unlock
Parking Lights Brown
Brake Lt. Green
HS CAN High N/A
HS CAN Low N/A
11
Pin Polarity Location
4 Data (PATS) connector.
3 Data (PATS) connector.
2 (+) Brake pedal switch.
9 (+) Ignition switch.
1 (+) Ignition switch.
10 (+) Ignition switch.
7 (+) Ignition switch.
7 (+) Ignition switch.
5 (+) Ignition switch.
3 or (+) Ignition switch.
10
10 (+) Drivers kick or LCM (Lighting Control Module) right of steering
column.
6 Data OBDII.
14 Data OBDII.
7 (+) Drivers kick or DDM in drivers door.
22 (-) DDM (Drivers Door Module) in drivers door.
12 (+) Trunk release switch or DDM in drivers door.
N/A (-) Drivers kick panel door harness.
N/A (-) Drivers kick panel door harness.
4 Data (PATS) connector Type 2.
3 Data (PATS) connector Type 2.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
16 (-) GEM (General Electronic Module) right of gas pedal.
10 (-) GEM right of gas pedal.
MUX GEM right of gas pedal or driver kick panel, (-) trigger thru
1000Ω resistor.
23
(-) GEM right of gas pedal or driver kick panel.
N/A (+) Drivers kick panel harness to rear.
N/A (+) Drivers kick panel.
N/A N/A N/A
N/A N/A N/A
Connector Information
Color
Black
Black
Brown
Gray
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Black
Gray
Black
Black
N/A
N/A
Green
Green
Black
Black
Black
Black
Black
Gray
Gray
Gray
N/A
N/A
N/A
N/A
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
5 D
10 B
10 B
10 B
10 B
10 B
10 B
10 B
13 E
16 L
16 L
24 M
26 M
26 M
N/A C
N/A C
4 A
4 A
7 B
7 B
7 B
7 B
7 B
22 E
22 E
26 E
N/A C
N/A C
N/A N/A
N/A N/A
DS4+ FORD1
