Directed Directechs DS4+ Installation Manual page 27

Wire Information
Function Color
Mercury Sable 2002-2005
RX Gray/Orange or
Brown/Yellow
TX White/Lt. Green or
Gray/Red
Parking Lights Brown
12V Lt. Green/Violet
Ignition Red/Lt. Green
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
HS CAN High - (2004-2005) White/Orange
HS CAN Low - (2004-2005) Pink/Orange
Keysense Black/Pink
Hood Trigger Tan/Lt. Green
Driver Door Trigger Yellow/Black
Lock Pink/Yellow
Unlock Pink/Lt. Green
Trunk Release Violet/Yellow
Brake Red/Lt. Green
Driver Rear Door Trigger Green/Yellow
Passenger Front Door Trigger Gray/Red
Passenger Rear Door Trigger Pink/Lt. Blue
27
Pin Polarity Location
3 Data (PATS) connector Type 1.
4 Data (PATS) connector Type 1.
12 (-) Headlight switch.
B3 (+) Ignition switch.
I1 (+) Ignition switch.
STA (+) Ignition switch.
A4 (+) Ignition switch.
A2 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
17 (-) GEM (Generic Electronic Module) left of steering column.
17 (-) GEM left of steering column.
5 (-) GEM left of steering column.
18 (-) GEM left of steering column.
6 (-) GEM left of steering column.
3 (-) GEM left of steering column.
1 or 2 (+) Brake pedal switch.
20 (-)
GEM left of steering column.
19 (-) Required ONLY when enabling the security features during module
flashing.
7 (-)
Connector Information
Color
N/A
N/A
Gray
Black
Black
Black
Black
Black
Black
Black
Black
White
White
White
White
White
Black
N/A
N/A
N/A
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
12 F
15 B
15 B
15 B
15 B
15 B
16 L
16 L
20 J
26 J
26 J
26 J
26 J
26 J
N/A D
26 J
26 J
26 J
DS4+ FORD1
